LSS128 by Dixon Valve | Style LSS | Quick-Release Worm Gear Clamp | 1/2" Band Width | Hose OD Range: from 1-3/4" to 8-1/2" | 201 Stainless Steel Band | 410 Stainless Steel Screw

LSS128 by Dixon Valve | Style LSS | Quick-Release Worm Gear Clamp | 1/2" Band Width | Hose OD Range: from 1-3/4" to 8-1/2" | 201 Stainless Steel Band | 410 Stainless Steel Screw

Sale price$10.64

Dixon Valve
Quick-Release Worm Gear Clamps | Style LSS
Buy More, Save More!
Quantity Price Each
10–39 $10.00
40–79 $9.04
80+ $7.98
Discounts applied in cart/checkout.

Product Data:

Series:
  • Style LSS
Material(s):
  • 201 Stainless Steel
  • 410 Stainless Steel
Clamp Width:

0.5"
Features:
  • Screw design: 5/16" slotted hex head.
  • Suggested installation torque 25-35 in. lbs., maximum recommended torque 50 in. lbs.
  • Torque ratings correspond to the torque rating of the screw of the clamp and are not an indication of the working pressure of any hose assembly installed with this clamp.
Materials:
  • Band and housing: 201-series stainless.
  • Style LS Screw: plated hardened carbon steel.
  • Style LSS Screw: SAE 410-series stainless.
Part Number
Style LS		 Part Number
Style LSS		 Band Width Hose OD
From To
LS48 LSS48 1/2" 1-1/2" 3-1/2"
LS56 - 1/2" 1" 4"
LS72 LSS72 1/2" 2" 5"
LS88 LSS88 1/2" 2" 6"
LS96 - 1/2" 3-1/2" 6-1/2"
LS104 LSS104 1/2" 2-7/8" 7"
LS128 LSS128 1/2" 1-3/4" 8-1/2"
LS152 - 1/2" 2" 10"
LS188 LSS188 1/2" 2" 12-1/4"
- LSS216 1/2" 10-3/16" 14"
- LSS248 1/2" 1-3/4" 16"
- LSS312 1/2" 1-7/8" 20"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
