HU206100N by Dixon Valve | Boss® LPS Hammer Union Nut | Figure 200/206 | One-Piece | 1" Size | Forged Steel (AISI Standard)

HU206100N by Dixon Valve | Boss® LPS Hammer Union Nut | Figure 200/206 | One-Piece | 1" Size | Forged Steel (AISI Standard)

Sale price$25.01

Dixon Valve
Boss® | LPS Hammer Union Nut | One-Piece

Used with Boss Low Pressure System Frac Fittings.
Buy More, Save More!
Quantity Price Each
10–39 $23.51
40–79 $21.26
80+ $18.76
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Boss
Shape:

No Orientation

Material(s):
  • Steel
Features:
  • Long lasting and dependable.
  • 6" and 8" sizes have 4-lug design for more surface area to hammer.
  • All nuts are interchangeable with reliable brands.
Construction:
  • 3 lug design.
  • Forged steel meets AISI standards.
Specification:
  • Cold working pressure: Figure 100 1,000 PSI, Figure 200/206 2,000 PSI.
Part Number Size Figure
HU206100N 1" 200/206
HU206200N 2" 200/206
HU100300N 3" 100
HU206300N 3" 200/206
HU100400N 4" 100
HU206400N 4" 200/206
HU100600N 6" 100
HU206600N 6" 200/206
HU100800N 8" 100
HU206800N 8" 200/206

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
