HESS-5X8 by Campbell Fittings | Expander | 1-1/4" Male NPT Thread x 2" Hose Barb | 316 Stainless Steel

HESS-5X8 by Campbell Fittings | Expander | 1-1/4" Male NPT Thread x 2" Hose Barb | 316 Stainless Steel

Sale price$89.00

by Campbell
Combination Nipples & Menders:HESS Expander Nipple
Buy More, Save More!
Quantity Price Each
5–19 $83.66
20–59 $75.65
60+ $66.75
Discounts applied in cart/checkout.

Product Data:

Series:
  • HESS Series
Shape:

Straight

Ends Configuration:
  • 1-1/4in Male NPT
  • 2in Hose Barb
Recommended Use:
  • Liquid, bulk handling, low pressure air
Recommended Hose Attachments:
  • Sleeves
  • Preformed Bands Clamps
Features and Benefits:
  • Maximum number of serrations for maximum holding power
  • Long lead serration for easier hose insertion
  • Formed hex wrench area on 3/4" through 1-1/2" combination nipples for easier installation
Part Number Hose Size
HESS-2X3 1/2" x 3/4"
HESS-3X4 3/4" x 1"
HESS-4X5 1" x 1-1/4"
HESS-4X6 1" x 1-1/2"
HESS-5X6 1-1/4" x 1-1/2"
HESS-5X8 1-1/4" x 2"
HESS-6X8 1-1/2" x 2"
HESS-8X10 2" x 2-1/2"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
