H2003 by Fenner Drives | B-LOC Shrink Disc SD30 | Heavy Duty | Size: 200-30 | Shaft Diameter Range: 6-1/4"-6.449" | Steel
Fenner Drives - Power Transmission - Keyless Locking Devices - B-LOC® Shrink Disc SD30 - Heavy Duty
Product Data:
Brand:
Series:
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
|||
| Notes: | |||
|
SPECIFICATIONS
| Series: | SD10 | Axial Movement: | No |
|---|---|---|---|
| Installation Torque: | N/A | Internal/ External: | N/A |
| Material: | Zinc Chromate/Chrome Plated Steel | Metric/Inch: | Inch |
| Releasing/ Locking: | Releasing | Screw Size: | N/A |
| Self-Centering: | Yes | Shaft Diameter: | N/A |
| Taper: | Double | Torque Max: | N/A |
| Torque Min: | N/A |
| Ma | Mt | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Size | SD Bore (Hub OD) | Hub OD Tolerance | Shaft Diameter Range | Locking Screws | Install Torque | Max. Transmitted Torque | ||||||||||
| d (inches) | TLd (Inch) | ds-MIN (ft lb) | ds-MAX (ft lb) | Qty | Size | (ft lb) | ds-MIN (ft lb) | ds-MAX (ft lb) | A (inch) | D (inch) | L (inch) | H (inch) | e (inch) | d1 (inch) | R (inch) | ||
| H0443 | 44-30 | 1.732" | + 0 / -0.002" | 1-1/8" | 1.419" | 5 | M8 x 30 | 22 ft lb | 941 ft lb | 1653 ft lb | 2.598" | 3.35" | 1.102" | 1.34" | 0.119" | 1.890" | 1/16" |
| H0503 | 50-30 | 1.969" | + 0 / -0.002" | 1-3/8" | 1.612" | 7 | M8 x 35 | 22 ft lb | 1761 ft lb | 2749 ft lb | 2.874" | 3.74" | 1.181" | 1.54" | 0.180" | 1.984" | 1/16" |
| H0553 | 55-30 | 2.165" | + 0 / -0.002" | 1-1/2" | 1.773" | 7 | M8 x 35 | 22 ft lb | 1892 ft lb | 3023 ft lb | 3.071" | 4.13" | 1.181" | 1.54" | 0.180" | 2.323" | 3/32" |
| B0623 | 62-30 | 2.441" | + 0 / -0.002" | 1-3/4" | 1.999" | 7 | M8 x 35 | 22 ft lb | 2353 ft lb | 3244 ft lb | 3.346" | 4.53" | 1.181" | 1.54" | 0.180" | 2.598" | 3/32" |
| B0683 | 68-30 | 2.677" | + 0 / -0.002" | 1-7/8" | 2.193" | 8 | M8 x 35 | 22 ft lb | 2861 ft lb | 4173 ft lb | 3.622" | 4.72" | 1.181" | 1.54" | 0.180" | 2.835" | 3/32" |
| B0753 | 75-30 | 2.953" | + 0 / -0.002" | 2-1/8" | 2.418" | 7 | M10 x 40 | 44 ft lb | 4552 ft lb | 6529 ft lb | 4.134" | 5.71" | 1.417" | 1.81" | 0.197" | 3.307" | 1/8" |
| B0803 | 80-30 | 3.150" | + 0 / -0.002" | 2-3/8" | 2.580" | 7 | M10 x 40 | 44 ft lb | 5541 ft lb | 6971 ft lb | 4.134" | 5.71" | 1.417" | 1.81" | 0.197" | 3.307" | 1/8" |
| B0903 | 90-30 | 3.543" | + 0 / -0.004" | 2-1/2" | 2.902" | 8 | M10 x 40 | 44 ft lb | 5946 ft lb | 8994 ft lb | 4.567" | 6.30" | 1.575" | 1.97" | 0.198" | 3.701" | 1/8" |
| B1003 | 100-30 | 3.937" | + 0 / -0.004" | 2-7/8" | 3.224" | 10 | M10 x 45 | 44 ft lb | 9370 ft lb | 12700 ft lb | 4.961" | 6.69" | 1.732" | 2.13" | 0.199" | 4.094" | 1/8" |
| H1103 | 110-30 | 4.331" | + 0 / -0.004" | 3-1/8" | 3.547" | 12 | M10 x 45 | 44 ft lb | 12116 ft lb | 16879 ft lb | 5.354" | 7.28" | 1.969" | 2.36" | 0.196" | 4.482" | 1/8" |
| H1253 | 125-30 | 4.921" | + 0 / -0.004" | 3-1/2" | 4.031" | 12 | M12 x 50 | 74 ft lb | 20092 ft lb | 28393 ft lb | 6.299" | 8.47" | 2.126" | 2.60" | 0.237" | 5.157" | 3/16" |
| B1403 | 140-30 | 5.512" | + 0 / -0.004" | 4" | 4.514" | 12 | M12 x 60 | 74 ft lb | 23275 ft lb | 31491 ft lb | 6.889" | 9.06" | 2.362" | 2.92" | 0.279" | 5.744" | 3/16" |
| H1553 | 155-30 | 6.102" | + 0 / -0.004" | 4-1/2" | 4.998" | 15 | M12 x 60 | 74 ft lb | 34154 ft lb | 42273 ft lb | 7.795" | 10.36" | 2.598" | 3.15" | 0.276" | 6.614" | 3/16" |
| H1653 | 165-30 | 6.496" | + 0 / -0.004" | 4-7/8" | 5.320" | 10 | M16 x 70 | 185 ft lb | 46957 ft lb | 58743 ft lb | 8.267" | 11.42" | 2.834" | 3.47" | 0.318" | 6.940" | 3/16" |
| H1753 | 175-30 | 6.890" | + 0 / -0.004" | 5-1/4" | 5.643" | 10 | M16 x 70 | 185 ft lb | 51804 ft lb | 62320 ft lb | 8.661" | 11.82" | 2.834" | 3.47" | 0.318" | 7.322" | 3/16" |
| H1853 | 185-30 | 7.283" | + 0 / -0.004" | 5-5/8" | 5.965" | 15 | M16 x 80 | 185 ft lb | 86847 ft lb | 100371 ft lb | 9.291" | 12.99" | 3.622" | 4.41" | 0.394" | 7.704" | 3/16" |
| H1953 | 195-30 | 7.677" | + 0 / -0.004" | 5-7/8" | 6.288" | 15 | M16 x 80 | 185 ft lb | 89488 ft lb | 105820 ft lb | 9.685" | 13.78" | 3.622" | 4.41" | 0.394" | 8.102" | 1/4" |
| H2003 | 200-30 | 7.874" | + 0 / -0.004" | 6-1/4" | 6.449" | 15 | M16 x 80 | 185 ft lb | 100466 ft lb | 108524 ft lb | 9.685" | 13.78" | 3.622" | 4.41" | 0.394" | 8.102" | 1/4" |
Metric hex head locking screws DIN 931 grade 10.9 (See Ma for install torque).
