FSCV100 by Dixon Valve | Check Valve | 1" Female NPT x 1" Female NPT | Forged Steel

FSCV100 by Dixon Valve | Check Valve | 1" Female NPT x 1" Female NPT | Forged Steel

Sale price$163.47

Dixon Valve & Coupling
Check Valve | Forged Steel

Can be used for steam service.
Buy More, Save More!
Quantity Price Each
5–19 $153.66
20–59 $138.95
60+ $122.60
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Ends Configuration:
  • 1in Female NPT
  • 1in Female NPT
  • Some Ends Match
Material(s):
  • Forged Steel
Features:
  • ASTM A105, ANSI B120.1.
  • Bolted bonnet.
Specifications:
  • Class 800
  • Pressure rating: 1975 PSI
  • Maximum temperature: 800°F (427°C)
Part Number Female NPT x Female NPT
FSCV50 1/2" x 1/2"
FSCV75 3/4" x 3/4"
FSCV100 1" x 1"
FSCV125 1-1/4" x 1-1/4"
FSCV150 1-1/2" x 1-1/2"
FSCV200 2" x 2"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
