FF12MSAE by Midland | Hydraulic Quick Disconnect | FF Series | Flush Face ISO 16028 Plug | 1/2" Body Size x 1/2" Female SAE O-Ring Boss | Steel
Midland Industries
Hydraulic Quick Disconnects: FF Series - Flush Face ISO 16028 Plug - Steel
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $25.27 |
| 40–79 | $22.85 |
| 80+ | $20.16 |
Discounts applied in cart/checkout.
Product Data:
Series:
Ends Configuration:
Material(s):
| Features: | |||
|---|---|---|---|
|
| Flush Face Series | ||||||||
|---|---|---|---|---|---|---|---|---|
| Body Size | Steel Coupler/ Plug Coupled | |||||||
| Maximum Working | Burst | |||||||
| PSI | Bar | PSI | Bar | |||||
| 1/4" | 5,000 PSI | 345 Bar | 18,270 PSI | 1,200 Bar | ||||
| 3/8" | 4,000 PSI | 275 Bar | 18,270 PSI | 1,200 Bar | ||||
| 1/2" | 4,000 PSI | 275 Bar | 16,500 PSI | 1,100 Bar | ||||
| 5/8" | 4,000 PSI | 275 Bar | 14,800 PSI | 1,000 Bar | ||||
| 3/4" | 4,000 PSI | 275 Bar | 12,400 PSI | 850 Bar | ||||
| 1" | 3,000 PSI | 200 Bar | 12,600 PSI | 850 Bar | ||||
| FF Series | Flush Face ISO 16028 Socket | |||||||||
|---|---|---|---|---|---|---|---|---|---|
 |
|||||||||
| Part Number | Body Size |
Female SAE O-Ring Boss |
Thread | ||||||
| FF14FSAE | 1/4" | 1/4" | 7/16-20 | ||||||
| FF38FSAE | 3/8" | 3/8" | 9/16-18 | ||||||
| FF3812FSAE | 3/8" | 1/2" | 3/4-16 | ||||||
| FF12FSAE | 1/2" | 1/2" | 3/4-16 | ||||||
| FF1234FSAE | 1/2" | 3/4" | 1-1/16-12 | ||||||
| FF1FSAE | 1" | 1" | 1-5/16-12 | ||||||
| FF Series | Flush Face ISO 16028 Plug | |||||||||
|---|---|---|---|---|---|---|---|---|---|
 |
|||||||||
| Part Number | Body Size |
Female SAE O-Ring Boss |
Thread | ||||||
| FF14MSAE | 1/4" | 1/4" | 7/16-20 | ||||||
| FF38MSAE | 3/8" | 3/8" | 9/16-18 | ||||||
| FF3812MSAE | 3/8" | 1/2" | 3/4-16 | ||||||
| FF12MSAE | 1/2" | 1/2" | 3/4-16 | ||||||
| FF1234MSAE | 1/2" | 3/4" | 1-1/16-12 | ||||||
| FF1MSAE | 1" | 1" | 1-5/16-12 | ||||||
