DDA400AL164TTMA by Dixon Valve | MannTek Dry Disconnect Adapter | Tank Unit | 4" TTMA Flange | 164mm Body Size | Aluminum

DDA400AL164TTMA by Dixon Valve | MannTek Dry Disconnect Adapter | Tank Unit | 4" TTMA Flange | 164mm Body Size | Aluminum

Sale price$976.74
Factory Order - Lead Time Applies
Buy more, save moreDiscounts applied in cart/checkout.
Compatibility & Interchange Data:
  • Compatible with Mann-Tek, Avery Hardoll and Todo-matic® and any other product produced according to NATO standard STANAG 3756.
Construction:
  • Standard seal supplied: FKM (FPM).
  • Aluminum poppet.
  • Stainless steel internal parts.
Features:
  • Adapter is usually installed on the tank or manifold.
  • Conical valve seat reduces the risk for piston blow out.
  • PTFE bearing between the piston shaft and the piston guide eliminate the risk for seizure.
  • Easy to handle - push and turn - free flow, turn and pull - closed.
  • Time saving - no need to drain hoses or pipe systems.
  • Economical - no loss or spillage of liquids at connection or disconnection.
  • Safety - the valve cannot be opened until the unit is coupled.
  • Environmental friendly - accidental spillage eliminated when properly used.
  • Safe and reliable - due to rugged construction.
  • Product life - uncomplicated design and high quality materials ensures long product life.
Specifications:
  • Produced according to NATO standard STANAG 3756 and ATOFINA SGM 2049.TUY.C.
  • Working pressure is based on PSI at ambient temperature 70°F.
    • Aluminum: 230 PSI, up to 4"
Use:
  • Use with composite (Polyeten PE-HD 300) caps for protection against corrosion; caps withstand hot and cold environments.
Aluminum
Part Number		 TTMA Flange Body Size
DDA300AL105TTMA 3" 105mm
DDA300AL119TTMA 3" 119mm
DDA400AL164TTMA 4" 164mm

Additional Product Data:

Brand:
  • MannTek
Shape:

Straight

Ends Configuration:
  • 164mm Male Manntek Dry Disconnect
  • 4in TTMA Flange

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
