CVV2BF2 Dixon Valve Steel CVV-Series Quick Disconnect 1/4" European Interchange Hydraulic Nipple - 1/4"-19 Female BSPP
Dixon

CVV2BF2 Dixon Valve Steel CVV-Series Quick Disconnect 1/4" European Interchange Hydraulic Nipple - 1/4"-19 Female BSPP

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

Construction:
  • Machined components are manufactured using solid bar stock.
  • Steel retaining rings and springs maximize service life in rugged environments.
  • Steel componentry is plated using ROHS Compliant Trivalent Chrome.
  • Nipples have a PTFE Anti-Extrusion ring to prevent O-Ring damage during dynamic impulse service.
Compatibility & Interchange Data:
  • European Screw-Together Interchange
  • Inteva STG-Series
  • Faster CVV-Series
  • DNP PVV3
  • Voswinkel Type-HS
  • Stucchi VD Series
Seal Components:
  • Nitrile (Buna-N) seals are standard, providing a temperature range of -13 deg. F to +257 deg. F (-25 deg. C to +125 deg. C).
  • Nipples have a PTFE Anti-Extrusion ring to prevent O-ring damage during dynamic impulse service.
Other Components:
Part Number Size Female Threads Material Length Max. OD Hex Max. Operating Pressure Burst Pressure Weight (Lbs.)
in. mm in. mm in. mm
CVV2F2 1/4" 1/4"-18 NPTF steel 2.36" 60.0mm 0.94" 24.0mm 3/4" 19mm 6500 PSI 26000 PSI 0.2500
CVV2BF2 1/4" 1/4"-19 BSPP steel 2.36" 60.0mm 0.94" 24.0mm 3/4" 19mm 6500 PSI 26000 PSI 0.2500
CVV2FM1415 1/4" M14X1.5 steel 2.36" 60.0mm 0.94" 24.0mm 3/4" 19mm 6500 PSI 26000 PSI 0.2300
CVV3F3 3/8" 3/8"-18 NPTF steel 2.52" 64.0mm 1.10" 28.0mm 7/8" 22mm 6500 PSI 26000 PSI 0.4900
CVV3BF3 3/8" 3/8"-19 BSPP steel 2.52" 64.0mm 1.10" 28.0mm 7/8" 22mm 6500 PSI 26000 PSI 0.4900
CVV3FM1615 3/8" M16X1.5 steel 2.52" 64.0mm 1.10" 28.0mm 7/8" 22mm 6500 PSI 26000 PSI 0.4600
CVV4F4 1/2" 1/2"-14 NPTF steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 5800 PSI 23200 PSI 0.7500
CVV4OF4 1/2" 3/4"-16 ORB steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 5800 PSI 23200 PSI 0.7500
CVV4BF4 1/2" 1/2"-14 BSPP steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 5800 PSI 23200 PSI 0.7600
CVV4FM1815 1/2" M18X1.5 steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 5800 PSI 23200 PSI 0.7800
CVV4OF5 1/2" 7/8"-14 ORB steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 5800 PSI 23200 PSI 0.7800
CVV4FM2215 1/2" M22X1.5 steel 2.76" 70.0mm 1.42" 36.0mm 1-1/16" 27mm 4400 PSI 17600 PSI 0.7500
CVV6F6 3/4" 3/4"-14 NPTF steel 3.39" 86.0mm 1.65" 42.0mm 1-7/16" 36mm 5800 PSI 23200 PSI 1.2800
CVV6BF6 3/4" 3/4"-14 BSPP steel 3.39" 86.0mm 1.65" 42.0mm 1-7/16" 36mm 5800 PSI 23200 PSI 1.2800
CVV6FM2215 3/4" M22X1.5 steel 3.39" 86.0mm 1.65" 42.0mm 1-7/16" 36mm 5800 PSI 23200 PSI 1.2800
CVV8F8 1" 1"-11 1/2 NPTF steel 3.94" 100.0mm 1.89" 48.0mm 1-5/8" 41mm 4400 PSI 17600 PSI 1.7800
CVV8BF8 1" 1"-11 BSPP steel 3.94" 100.0mm 1.89" 48.0mm 1-5/8" 41mm 4400 PSI 17600 PSI 1.7800
CVV10F10 1-1/4" 1-1/4"-11 1/2 NPTF steel 5.91" 150.0mm 2.76" 70.0mm 2" 50mm 4400 PSI 17600 PSI 2.6400
CVV10BF10 1-1/4" 1-1/4"-11 BSPP steel 5.91" 150.0mm 2.76" 70.0mm 2" 50mm 4400 PSI 17600 PSI 2.6400
