CFR47-150-200 Dixon Continuous Flow Reel - 1-1/2" Female NPT Inlet Size x 1-1/2" Male NST(NH) Outlet - Capacity: 200' of 1-1/2" Hose
Dixon Fire Fittings
Fire Hose - Racks & Reels - Continuous Flow Reel
Allows immediate and continuous flow of water at all times during deployment of hose.
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $1,988.64 |
| 8–14 | $1,904.01 |
| 15+ | $1,692.46 |
Discounts applied in cart/checkout.
Product Data:
| Features: | |||
|---|---|---|---|
|
|||
| Note: | |||
|
 |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Female NPT Inlet Size |
Male NST(NH) Outlet Size |
Hose Size and Capacity | Dimensions | Weight (Lbs.) |
Vinyl Cover | ||||||||
| 3/4" | 1" | 1-1/2" | A | B | C | D | E | F | G | |||||
| CFR47-1-100 | 1" | 1" | 150ft | 125ft | - | 10-1/2" | 11-1/2" | 24" | 19-1/4" | 24" | 21-3/4" | 26" | 88.0000 | CFR47-C1 |
| CFR47-150-100 | 1-1/2" | 1-1/2" | 250ft | 150ft | 100ft | 10-1/2" | 20-1/2" | 24" | 28-1/4" | 33" | 21-3/4" | 26" | 60.0000 | CFR47-C3 |
| CFR47-1-200 | 1-1/2" | 1-1/2" | 400ft | 300ft | 150ft | 10-1/2" | 28" | 24" | 35-3/4" | 40-1/2" | 21-3/4" | 26" | 111.0000 | CFR47-C2 |
| CFR47-150-200 | 1-1/2" | 1-1/2" | - | - | 200ft | 10-1/2" | 34" | 24" | 41-3/4" | 46-1/2" | 21-3/4" | 26" | 100.5000 | CFR47-C4 |
| Optional Accessories | ||
|---|---|---|
| Part Number | Description | Weight |
| DX2836 | 1" x 18" flexible connector (male NPT x male NPT) | 1.1100 |
| DX2839 | 1-1/2" x 18" flexible connector (male NPT x male NPT) | 2.0200 |
| CFR-HC | Hand Crank | 1.7300 |
| CFR-RK | Repair Kit, Contains: - O-ring - PTFE retaining ring for the inlet casting - Spacer washer - 2 Steel retaining rings for the manifold |
1.2390 |
