BV2BV-02511 Dixon Valve 1/4" Two-Piece Industrial Brass Ball Valve - Female NPT x Female NPT - PTFE Seat - No Handle
Dixon

BV2BV-02511 Dixon Valve 1/4" Two-Piece Industrial Brass Ball Valve - Female NPT x Female NPT - PTFE Seat - No Handle

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

What are the Features?

  • Full port
  • Female NPT ends
  • Blow-out proof stem
  • ISO 5211 mounting pad

How is it Constructed?

  • PTFE seats with O-ring backing
  • Double O-ring stem packing
  • ISO 5211 mounting pad

What are the Specifications?

  • Maximum Operating Pressure: 600 PSI WOG
  • Maximum Temperature: 320°F (160°C)
Part Number Size Body Seat Handle Dimensions
A B C D E F Break Torque (in. lbs.)
BV2BV-02511 1/4" Brass PTFE No Handle - 1.28" 2.64" F03 - 9mm 53 in. lbs.
