BR-F050 by Kuriyama | BR-F Series | Part F | Cam & Groove Adapter | 1/2" Adapter x 1/2" Male NPT | Brass
Kuriyama of America Inc.
Cam & Groove (Camlock) Adapter | BR-F Series | Part F | Adapter x Male NPT | Brass
Kuriyama Camlock Couplings are intended for use in many industrial applications.
High quality design made to withstand rigorous applications found in industrial markets.
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $15.96 |
| 40–79 | $14.43 |
| 80+ | $12.74 |
Discounts applied in cart/checkout.
What are the Applications?
- Kuriyama Camlock Couplings are intended for use in many industrial applications.
- Highly resistant to damage and corrosion.
- Brass performs especially well against saltwater corrosion, so it is commonly found in marine applications.
What are the Features?
- High quality design made to withstand rigorous applications found in industrial markets.
- Brass alloy specially designed for high tensile strength, impact resistance, and rigidity.
What are the Materials?
- ASTM brass alloy.
- Complies with Mil-Spec A-A-59326 for interchangeability in relevant sizes.
| Part Number | Size (in) |
PSI Rating at 70°F |
ASTM Specification |
Weight Each (lbs) |
|---|---|---|---|---|
| BR-F050 | 1/2" | 250 PSI | B584 C85700 | 0.22 lbs |
| BR-F075 | 3/4" | 250 PSI | B584 C85700 | 0.33 lbs |
| BR-F100 | 1" | 250 PSI | B584 C85700 | 0.53 lbs |
| BR-F125 | 1-1/4" | 250 PSI | B584 C85700 | 0.66 lbs |
| BR-F150 | 1-1/2" | 250 PSI | B584 C85700 | 0.88 lbs |
| BR-F200 | 2" | 250 PSI | B584 C85700 | 1.08 lbs |
| BR-F250 | 2-1/2" | 150 PSI | B584 C85700 | 1.85 lbs |
| BR-F300 | 3" | 150 PSI | B584 C85700 | 2.42 lbs |
| BR-F400 | 4" | 150 PSI | B584 C85700 | 3.74 lbs |
| BR-F500 | 5" | 75 PSI | B584 C85700 | 4.63 lbs |
| BR-F600 | 6" | 75 PSI | B584 C85700 | 9.03 lbs |
Product Data:
Series:
MAWP:
250
Shape:
Straight
Cam & Groove Type:
Type F
Ends Configuration:
Material(s):
