BR-DP400 by Kuriyama | BR-DP Series | Part DP | Cam & Groove Dust Plug | 4" Size | Brass
Kuriyama of America Inc.
Cam & Groove (Camlock) Dust Plug | BR-DP Series | Part DP | Brass
Kuriyama Camlock Couplings are intended for use in many industrial applications.
High quality design made to withstand rigorous applications found in industrial markets.
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $81.45 |
| 20–59 | $73.65 |
| 60+ | $64.99 |
Discounts applied in cart/checkout.
What are the Applications?
- Kuriyama Camlock Couplings are intended for use in many industrial applications.
- Highly resistant to damage and corrosion.
- Brass performs especially well against saltwater corrosion, so it is commonly found in marine applications.
What are the Features?
- High quality design made to withstand rigorous applications found in industrial markets.
- Brass alloy specially designed for high tensile strength, impact resistance, and rigidity.
What are the Materials?
- ASTM brass alloy.
- Complies with Mil-Spec A-A-59326 for interchangeability in relevant sizes.
| Part Number | Size (in) |
PSI Rating at 70°F |
ASTM Specification |
Weight Each (lbs) |
|---|---|---|---|---|
| BR-DP075 | 3/4" | 250 PSI | B584 C85700 | 0.22 lbs |
| BR-DP100 | 1" | 250 PSI | B584 C85700 | 0.33 lbs |
| BR-DP125 | 1-1/4" | 250 PSI | B584 C85700 | 0.46 lbs |
| BR-DP150 | 1-1/2" | 250 PSI | B584 C85700 | 0.53 lbs |
| BR-DP200 | 2" | 250 PSI | B584 C85700 | 0.99 lbs |
| BR-DP250 | 2-1/2" | 150 PSI | B584 C85700 | 1.20 lbs |
| BR-DP300 | 3" | 150 PSI | B584 C85700 | 1.65 lbs |
| BR-DP400 | 4" | 150 PSI | B584 C85700 | 2.42 lbs |
| BR-DP500 | 5" | 75 PSI | B584 C85700 | 3.74 lbs |
| BR-DP600 | 6" | 75 PSI | B584 C85700 | 4.74 lbs |
Product Data:
Series:
MAWP:
150
Cam & Groove Type:
Type DP
Ends Configuration:
Material(s):
