BBV100 by Dixon Valve | Domestic Ball Valve | Standard Port | 1" Female NPT x 1" Female NPT | Bronze

BBV100 by Dixon Valve | Domestic Ball Valve | Standard Port | 1" Female NPT x 1" Female NPT | Bronze

Sale price$95.73

Dixon Valve & Coupling
Domestic Ball Valve | Bronze

For control of air, water, oil, and gas in hose or pipe lines.
Buy More, Save More!
Quantity Price Each
5–19 $89.99
20–59 $81.37
60+ $71.80
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Ends Configuration:
  • 1in Female NPT
  • 1in Female NPT
  • Some Ends Match
Material(s):
  • Bronze
Features:
  • Blowout-proof stems
  • Full and standard port valves are repairable
Materials:
  • Bronze valve bodies, balls, and stems.
  • Glass-filled reinforced PTFE seats and stuffing box ring; stem seals and washers.
  • Plated steel handles and nuts with vinyl sleeves.
Specifications:
  • Pressure rating: 600 PSI CWP; 150 PSI saturated steam.
Approvals:
  • Meets WW-V 35C, Type II Composition
Part Number Female NPT Port
BBV25 1/4" Full
BBV38 3/8" Full
BBV50 1/2" Full
BBV75 3/4" Standard
BBV100 1" Standard
BBV125 1-1/4" Standard
BBV150 1-1/2" Standard
BBV200 2" Standard
BBV250 2-1/2" Standard
BBV300 3" Standard
