B152315 by Fenner Drives | B-Loc B115 | Medium Duty | 3-15/16" | Steel
Fenner Drives - Power Transmission - Keyless Locking Devices - B-Loc® B115 - Medium Duty - Steel - Inch
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $489.70 |
| 15–29 | $442.82 |
| 30+ | $390.72 |
Discounts applied in cart/checkout.
B152315 by Fenner Drives | B-Loc B115 | Medium Duty | 3-15/16" | Steel
Sale price$520.96
Product Data:
Brand:
Series:
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Series: | B115 | Torque Transmission: | N/A |
|---|---|---|---|
| Axial Movement: | N/A | Bore Tolerance: | N/A |
| Compliancy | N/A | Component Bore Diameter: | N/A |
| Hub Pressure: | N/A | Installation Torque: | N/A |
| Internal/ External: | N/A | Material: | Steel |
| Metric/Inch: | Inch | Releasing/ Locking: | N/A |
| Screw Size: | N/A | Self-Centering: | N/A |
| Shaft Diameter: | N/A | Shaft Tolerance: | N/A |
| Taper: | N/A | Thrust: | N/A |
| Part Number | d | D | L | L1 | Locking Screw Size | Ma | Mt Max. Transmitted |
Th Max. Transmitted |
Ph | |
|---|---|---|---|---|---|---|---|---|---|---|
| (inch) | (inch) | (inch) | (inch) | Qty | Size | Install Torque (ft lb) |
Torque (ft lb) |
Thrust (lbs) |
Hub Pressure (PSI) |
|
| B152212 | 2-3/4" | 4.331" | 1.969" | 2.441" | 8 | M10 x 50 | 60 ft lb | 5261 ft lb | 45913 lbs | 17858 |
| B152215 | 2-15/16" | 4.528" | 1.969" | 2.441" | 8 | M10 x 50 | 60 ft lb | 5620 ft lb | 45913 lbs | 17079 |
| T152307 | 3-7/16" | 5.118" | 1.969" | 2.441" | 11 | M10 x 50 | 60 ft lb | 9042 ft lb | 63131 lbs | 20777 |
| B152308 | 3-1/2" | 5.118" | 1.969" | 2.441" | 11 | M10 x 50 | 60 ft lb | 9207 ft lb | 63131 lbs | 20777 |
| B152315 | 3-15/16" | 5.709" | 2.362" | 2.835" | 10 | M12 x 60 | 105 ft lb | 14086 ft lb | 85858 lbs | 21111 |
| B152407 | 4-7/16" | 6.496" | 2.362" | 2.835" | 11 | M12 x 60 | 105 ft lb | 17462 ft lb | 94444 lbs | 20408 |
| T152408 | 4-1/2" | 6.496" | 2.362" | 2.835" | 11 | M12 x 60 | 105 ft lb | 17708 ft lb | 94444 lbs | 20408 |
| T152415 | 4-15/16" | 7.087" | 2.559" | 3.189" | 14 | M12 x 70 | 105 ft lb | 24729 ft lb | 120202 lbs | 21162 |
| T152500 | 5" | 7.087" | 2.559" | 3.189" | 14 | M12 x 70 | 105 ft lb | 25042 ft lb | 120202 lbs | 21162 |
| B152507 | 5-7/16" | 7.480" | 2.559" | 3.228" | 15 | M12 x 70 | 105 ft lb | 29178 ft lb | 128787 lbs | 21482 |
| B152515 | 5-15/16" | 7.874" | 2.559" | 3.228" | 15 | M12 x 70 | 105 ft lb | 31861 ft lb | 128787 lbs | 20407 |
| T152600 | 6" | 8.268" | 2.559" | 3.228" | 16 | M12 x 70 | 105 ft lb | 34343 ft lb | 137373 lbs | 20731 |
| T152607 | 6-7/16" | 8.858" | 3.071" | 3.661" | 15 | M14 x 80 | 166 ft lb | 47013 ft lb | 175273 lbs | 20830 |
| B152615 | 6-15/16" | 9.252" | 3.071" | 3.661" | 15 | M14 x 80 | 166 ft lb | 50665 ft lb | 175273 lbs | 19944 |
| B152715 | 7-15/16" | 10.236" | 3.465" | 4.134" | 18 | M14 x 80 | 166 ft lb | 69561 ft lb | 210328 lbs | 18216 |
| T152800 | 8" | 10.236" | 3.465" | 4.134" | 18 | M14 x 80 | 166 ft lb | 70109 ft lb | 210328 lbs | 18216 |
TOLERANCE (TL) Bore diameter machined to D -0/+TL TL = .002" for bores up to 4.724" .003" for bores up to 12.008" .004" for bores up to 25.000" .005" for bores over 25.000"
TL = .05mm for bores up to 120mm .08mm for bores up to 305mm .10mm for bores up to 635mm .13mm for bores over 635mm d = shaft diameter machined to d +0/-TL
