AK3526-300FL Dixon Brass Omega™ Monitor - 3" Waterway - 3" Flange Inlet x 2-1/2" Male NST(NH) Outlet

AK3526-300FL Dixon Brass Omega™ Monitor - 3" Waterway - 3" Flange Inlet x 2-1/2" Male NST(NH) Outlet

Sale price$5,634.13

Dixon Fire Fittings
Fire Nozzles - Omega™ Monitor - Brass

Factory Mutual approved.
Buy More, Save More!
Quantity Price Each
3–5 $5,296.08
6+ $5,070.72
Discounts applied in cart/checkout.

Product Data:

Shape:

Non-Standard Orientation

Material(s):
  • Brass
Features:
  • Cast-in turning vanes for a more efficient flow.
  • 360° horizontal and 150° vertical travel.
  • Friction loss: 10 PSI at 800 GPM (.7 bar at 3030 LPM).
  • 4 Bolt hole pattern on flange.
Part Number Size Inlet Outlet Waterway Flow Weight
(Lbs.)
AK3526-300FL 17" x 11-1/2" 3" Flange 2-1/2" Male NST(NH) 3" 1250 GPM 75.0000
AK4450NST Monitor Nozzle - 2-1/2" Female NST(NH) 14.5000
