AD90400EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupling | 90° Elbow | Type D | 4" Coupler x 4" Female NPT | Aluminum

AD90400EZ by Dixon Valve | EZ Boss-Lock Cam & Groove Coupling | 90° Elbow | Type D | 4" Coupler x 4" Female NPT | Aluminum

Sale price$208.13

Dixon Valve
Cam & Groove Coupler | 90° Elbow | Type D | Coupler x Female NPT

Designed for use with liquids.
Buy More, Save More!
Quantity Price Each
5–19 $195.64
20–59 $176.91
60+ $156.10
Discounts applied in cart/checkout.

Product Data:

Brand:
  • EZ Boss-Lock
MAWP:

100

Shape:

90 Degree
Construction:
  • Nitrile rubber gasket standard.
Safety Notes:
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F (21°C) with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
How It Works:
  • To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
  • Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
Specifications:
  • Produced to interchange with all product produced to Commercial Item Description A-A-59326D.
356T6 Aluminum
Part Number		 Brass
Part Number		 316 Stainless Steel
Part Number		 Size Maximum Operating Pressure
- - 100D-90SS 1" 250 PSI
- 125D-90BR - 1-1/4" 250 PSI
150D-90AL 150D-90BR - 1-1/2" 250 PSI
200D-90AL 200D-90BR 200D-90SS 2" 250 PSI
300D-90AL - 300D-90SS 3" 125 PSI
400D-90AL - 400D-90SS* 4" 100 PSI
AD90400EZ
(EZ Boss-Lock)		 - - 4" 100 PSI
600D-90AL - - 6" 75 PSI

* Parts are produced as a welded fabrication.

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
