A14 Air King® by Dixon Valve | Clamp for Pneumatic Fitting | 2-Bolt Type | 2-Gripping Fingers | 1" Hose ID | Hose OD: From 1-32/64" to 1-52/64" | Plated Iron

A14 Air King® by Dixon Valve | Clamp for Pneumatic Fitting | 2-Bolt Type | 2-Gripping Fingers | 1" Hose ID | Hose OD: From 1-32/64" to 1-52/64" | Plated Iron

Sale price$22.24

Dixon Valve
Air King® | Clamp for Pneumatic Fitting | 2-Bolt Type | 2-Gripping Fingers

Air King is for air and water service only.
Buy More, Save More!
Quantity Price Each
10–39 $20.91
40–79 $18.90
80+ $16.68
Discounts applied in cart/checkout.

Product Data:

Material(s):
  • Plated Iron
Minimum Clamp I.D.:

1.5"

Maximum Clamp I.D.:

1.8125"
Safety Notes:
  • Never use any Air King coupling for steam service!
  • Air King is for air and water service ONLY.
  • Torque values for clamps are based on dry bolts.
  • The use of lubricant on bolts will adversely effect clamp performance.
Plated Iron
Part Number		 Hose I.D. Hose O.D. Torque
ft. lbs.
From To
CD** 3/8" 44/64" 56/64" 6
A4 1/2" 1" 1-12/64" 6
A9** 3/4" 1-8/64" 1-20/64" 21
A10*,** 1" 1-20/64" 1-32/64" 21
A14 1" 1-32/64" 1-52/64" 21

* Can be used with AM6 and AM11
** Global investment cast carbon steel

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
