BS099 - #99 Beltservice PVC - 350 Black C x C SC/FR Conveyor Belt

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
Feed Grain
Features:
The most common, best performance yield elevator belting available in the feed and grain industry. These belts feature low stretch, trouble free operation with high bucket bolt-holding ability. Resistant to grain oils, moisture, mildew, and rot.

	PVC - 250 Black C x C SC/FR Pt No.: 98a	PVC - 350 Black C x C SC/FR Pt No.: 99	PVC - 350 Black C x Brushed SC/FR Pt No.: 99a	PVC - 450 Black C x C SC/FR Pt No.: 100	PVC - 750 Black C x C SC/FR Pt No.: 101
Thickness	N/A	9/32"	N/A	5/16"	13/32"
Covers	N/A	C x C	N/A	C x C	C x C
Safe Work Load PIW Conveyor	N/A	350 lbs.	N/A	450 lbs.	750 lbs.
Safe Work Load PIW Elevator Allowable	N/A	350 lbs.	N/A	450 lbs.	750 lbs.
Safe Work Load PIW Elevator Preferred	N/A	280 lbs.	N/A	350 lbs.	500 lbs.
Max Bucket Projection Grain	N/A	8"	N/A	9"	9"
Max Bucket Projection Industrial	N/A	7"	N/A	9"	10"
Min. Pulley Diameter Conveyor / Elevator	N/A	8" / 12"	N/A	10" / 14"	14" / 18"
Temperature Range	N/A	0 deg. F / 180 deg. F	N/A	0 deg. F / 180 deg. F	0 deg. F / 180 deg. F
Approx. Weight Lbs. Per Inch Width	N/A	.158 lbs.	N/A	.175 lbs.	.208 lbs.
Clipper Lace	N/A	#5	N/A	#6	#7
Alligator Lace	N/A	#35	N/A	#45	#55
Alligator Staple / Flexco SR	N/A	R5 #550 Hinged	N/A	R5 #550 Hinged	R6 #550 Hinged
