944107 by Midland | Forged Mini Ball Valve | 1/8" Male Pipe x 1/8" Male Pipe | Brass

944107 by Midland | Forged Mini Ball Valve | 1/8" Male Pipe x 1/8" Male Pipe | Brass

Sale price$14.18

Midland Industries
Forged Mini Ball Valve - Male Pipe x Male Pipe - Brass

200 WOG working pressure
Buy More, Save More!
Quantity Price Each
10–39 $13.33
40–79 $12.05
80+ $10.64
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Ends Configuration:
  • 1/8in Male NPT
  • 1/8in Male NPT
Material(s):
  • Brass
Features:
  • Temp rating: -20°F - 250°F
  • Generic Handles
  • Not lead free
Construction:
  • 180° operational handle
  • Blow out proof stem
  • Stem with double "O" Rings
Number Part Name Material QTY
1 Nut Steel 1
2 Handle Steel 1
3 Cover PVC 1
4 O-Ring NBR 2
5 Stem Brass 1
6 Body Brass 1
7 Seat Teflon 2
8 Ball Disc Brass 1
9 End Plug Brass 1
Part Number Size A B C D
944107
(944-107)		 1/8" 1.70" 2.94" 0.65" 1.42"
944109
(944-109)		 1/4" 1.25" 2.66" 0.65" 1.42"
944110
(944-110)		 3/8" 1.90" 2.98" 0.73" 1.42"

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
