940139 by Midland | Gate Valve IPS | 3" Female Pipe x 3" Female Pipe | Brass
Midland Industries
Gate Valve IPS - Female Pipe x Female Pipe - Brass
200 PSI WOG
Full Port
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $253.11 |
| 15–29 | $228.88 |
| 30+ | $201.95 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Ends Configuration:
Material(s):
Seal Material(s):
| Features: | |||
|---|---|---|---|
|
|||
| Construction: | |||
|
|||
| Specifications: | |||
|
| Number | Description | Material |
|---|---|---|
| 1 | Body | C85700 |
| 2 | Disk | C85700 |
| 3 | Seat | PTFE |
| 4 | Cap | C85700 |
| 5 | Packing | C85700 |
| 6 | Stem | C85700 |
| 7 | Rubber Seat | NBR |
| 8 | Packing Nut | C85700 |
| 9 | Handle | Cast Iron |
| 10 | Nameplate | AL |
 |
||||||||
|---|---|---|---|---|---|---|---|---|
| Part Number | Size | L | H | D1 | D | T | S1 | Weight |
| 940130 (940-130) |
1/4" | 1.64" | 2.91" | 2.09" | 0.44" | 1/4-18 NPT | 0.85" | 0.60 |
| 940131 (940-131) |
3/8" | 1.71" | 2.91" | 2.09" | 0.48" | 3/8-18 NPT | 0.85" | 0.59 |
| 940132 (940-132) |
1/2" | 1.71" | 2.91" | 2.09" | 0.50" | 1/2-14 NPT | 1.03" | 0.75 |
| 940133 (940-133) |
3/4" | 1.71" | 3.06" | 2.13" | 0.74" | 3/4-14 NPT | 1.26" | 0.83 |
| 940134 (940-134) |
1" | 2.13" | 3.60" | 2.48" | 0.97" | 1-11.5 NPT | 1.15" | 1.24 |
| 940135 (940-135) |
1-1/4" | 2.24" | 4.50" | 2.66" | 1.22" | 1-1/4-11.5 NPT | 1.89" | 1.69 |
| 940136 (940-136) |
1-1/2" | 2.44" | 5.08" | 3.15" | 1.45" | 1-1/2-11.5 NPT | 2.17" | 2.17 |
| 940137 (940-137) |
2" | 2.70" | 5.94" | 3.52" | 1.85" | 2-11.5 NPT | 2.60" | 3.33 |
| 940138 (940-138) |
2-1/2" | 3.70" | 7.87" | 3.98" | 2.48" | 2-1/2-8 NPT | 3.27" | 6.26 |
| 940139 (940-139) |
3" | 4.02" | 8.82" | 4.37" | 2.80" | 3-8 NPT | 3.86" | 8.34 |
| 940140 (940-140) |
4" | 4.53" | 9.88" | 4.74" | 3.60" | 4-8 NPT | 4.88" | 13.09 |
