9325-06-16x1.5 by AdaptAll | -06 Male NPT x 16mm Female Metric | Solid Adapter | Carbon Steel

9325-06-16x1.5 by AdaptAll | -06 Male NPT x 16mm Female Metric | Solid Adapter | Carbon Steel

Sale price$26.60

Adaptall
Male NPT x Female Metric Solid Adapter - Carbon Steel

In stock
Buy More, Save More!
Quantity Price Each
10–39 $25.00
40–79 $22.61
80+ $19.95
Discounts applied in cart/checkout.

Product Data:

Series:
  • 9325 Series
Shape:

Straight

Material(s):
  • Carbon Steel
Features
  • Relevant Standard(s):
    • Side 1: ANSI B1.20.3
    • Side 2: ISO 9974 / DIN 7631
Part Number Side 1 Side 2 Dimensions Weight
Dash
Size		 Type Gender Size Thread Metric
Size		 Type Gender Size Thread L
(Length)		 CH
(Width)		 lbs.
9325-02-06x1.0 -02 NPT Male 1/8" 1/8 - 27 NPTF 6X1.0 METRIC Female 6X1.0 M6 X 1.0 22.5mm 13mm 0.05 lbs
9325-02-08x1.0 -02 NPT Male 1/8" 1/8 - 27 NPTF 8mm METRIC Female 8mm M8 X 1.0 27.9mm 13mm 0.05 lbs
9325-02-10x1.0 -02 NPT Male 1/8" 1/8 - 27 NPTF 10mm METRIC Female 10mm M10 X 1.0 32.2mm 14mm 0.05 lbs
9325-02-10x1.25 -02 NPT Male 1/8" 1/8 - 27 NPTF 10X1.25 METRIC Female 10X1.25 M10 X 1.25 27.7mm 16mm 0.05 lbs
9325-02-10x1.5 -02 NPT Male 1/8" 1/8 - 27 NPTF 10X1.5 METRIC Female 10X1.5 M10 X 1.5 32.2mm 14mm 0.05 lbs
9325-02-12x1.0 -02 NPT Male 1/8" 1/8 - 27 NPTF 12X1.0 METRIC Female 12X1.0 M12 X 1.0 30.6mm 19mm 0.04 lbs
9325-02-12x1.5 -02 NPT Male 1/8" 1/8 - 27 NPTF 12mm METRIC Female 12mm M12 X 1.5 25mm 17.5mm 0.1 lbs
9325-04-10x1.0 -04 NPT Male 1/4" 1/4 - 18 NPTF 10mm METRIC Female 10mm M10 X 1.0 N/A N/A N/A
9325-04-12x1.5 -04 NPT Male 1/4" 1/4 - 18 NPTF 12mm METRIC Female 12mm M12 X 1.5 28mm 19mm 0.09 lbs
9325-04-14x1.5 -04 NPT Male 1/4" 1/4 - 18 NPTF 14mm METRIC Female 14mm M14 X 1.5 33mm 19mm 0.1 lbs
9325-04-16x1.5 -04 NPT Male 1/4" 1/4 - 18 NPTF 16mm METRIC Female 16mm M16 X 1.5 34.9mm 22mm 0.1 lbs
9325-06-14x1.5 -06 NPT Male 3/8" 3/8 - 18 NPTF 14mm METRIC Female 14mm M14 X 1.5 39mm 20.5mm 0.15 lbs
9325-06-16x1.5 -06 NPT Male 3/8" 3/8 - 18 NPTF 16mm METRIC Female 16mm M16 X 1.5 35.1mm 22mm 0.1 lbs
9325-06-18x1.5 -06 NPT Male 3/8" 3/8 - 18 NPTF 18mm METRIC Female 18mm M18 X 1.5 36mm 24mm 0.15 lbs
9325-08-14x1.5 -08 NPT Male 1/2" 1/2 - 14 NPTF 14mm METRIC Female 14mm M14 X 1.5 31.8mm 24mm 0.15 lbs
9325-08-18x1.5 -08 NPT Male 1/2" 1/2 - 14 NPTF 18mm METRIC Female 18mm M18 X 1.5 39.4mm 24mm 0.15 lbs
9325-08-20x1.5 -08 NPT Male 1/2" 1/2 - 14 NPTF 20mm METRIC Female 20mm M20 X 1.5 39.7mm 27mm 0.12 lbs
9325-08-22x1.5 -08 NPT Male 1/2" 1/2 - 14 NPTF 22mm METRIC Female 22mm M22 X 1.5 44.3mm 28.5mm 0.2 lbs
9325-08-24x1.5 -08 NPT Male 1/2" 1/2 - 14 NPTF 24mm METRIC Female 24mm M24 X 1.5 41.9mm 32mm 0.21 lbs
9325-12-18x1.5 -12 NPT Male 3/4" 3/4 - 14 NPTF 18mm METRIC Female 18mm M18 X 1.5 N/A N/A N/A
9325-12-20x1.5 -12 NPT Male 3/4" 3/4 - 14 NPTF 20mm METRIC Female 20mm M20 X 1.5 N/A N/A N/A
9325-12-26x1.5 -12 NPT Male 3/4" 3/4 - 14 NPTF 26mm METRIC Female 26mm M26 X 1.5 52.6mm 35mm 0.45 lbs
9325-12-30x1.5 -12 NPT Male 3/4" 3/4 - 14 NPTF 30X1.5 METRIC Female 30X1.5 M30 X 1.5 45.9mm 38mm 0.04 lbs
9325-12-30x2.0 -12 NPT Male 3/4" 3/4 - 14 NPTF 30mm METRIC Female 30mm M30 X 2.0 45.8mm 38mm 0.43 lbs
9325-16-26x1.5 -16 NPT Male 1" 1 - 11.5 NPTF 26mm METRIC Female 26mm M26 X 1.5 N/A N/A 0.01 lbs
9325-20-30x1.5 -20 NPT Male 1-1/4" 1-1/4 - 11.5 NPTF 30X1.5 METRIC Female 30X1.5 M30 X 1.5 N/A N/A N/A

Dimensions shown here are for steel and stainless only.

Adaptall

Adaptall specializes in the conversion of hydraulic adapters and fittings, between International (“Metric”) and American (“Imperial”) thread types. These include British (BSPP, & BSPT), JIS, Kobelco, Komatsu, and Metric on the International side, as well as JIC, NPT, ORFS, and SAE ORB for Imperial thread types. Industries served include construction, mining / aggregates, pulp & paper, agriculture, manufacturing, industrial, marine, aerospace, military, OEM and more.
