9287X27 17 by Parker | Legris Plug Quick Disconnect | 3/8" Female BSPP Thread | 24 mm Hex | 56 mm Length | Stainless Steel

9287X27 17 by Parker | Legris Plug Quick Disconnect | 3/8" Female BSPP Thread | 24 mm Hex | 56 mm Length | Stainless Steel

Sale price$128.22

by Parker Hannifin
Series 27 - Stainless Steel:9287X27 Plug with valve, Male Thread
Buy More, Save More!
Quantity Price Each
20–29 $120.53
30–59 $108.99
60+ $96.17
Discounts applied in cart/checkout.

Product Data:

Series:
  • Series 27
Shape:

No Orientation

Ends Configuration:
  • 3/8in Female BSPP
Series 27 - Brass/Steel Series: Double Shut-Off 1/2" Universal industrial coupling with standard European profile for use with large pneumatic consumers. Coupling system with single-hand operation. High Flow valve for optimum flow and low pressure drop. The series stands out for its robust design, extremely high flow and long service life even with the harshest use. The collar design minimizes damage to the valve body.
      Available on request:
  • with additional end connections
  • other seals for different temperature ranges and fluids
Working Pressure:
  • up to 35 bar
Material:
  • Coupling: AISI 303 / AISI 316L
  • Plug: AISI 303 / AISI 316L
  • Seals: FKM
Working Temperature:
  • -15°C up to +200°C (FKM)
Flow Rate Air:
  • 950 l/min. (inlet pressure 6 bar, pressure dop 0.5 bar)
Flow Rate Water:
  • 14 l/min. (Pressure dop 0.5 bar)
Part Number A Hex L L1
9287X27 17 3/8" 24 mm 56 mm 9 mm

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
