9123 23 10 by Parker | Legris Coupler Quick Disconnect | 10 mm Hose Barb | 19 mm Hex | 74 mm Length | Straight | Nickel-Plated Brass | Pack of 5

9123 23 10 by Parker | Legris Coupler Quick Disconnect | 10 mm Hose Barb | 19 mm Hex | 74 mm Length | Straight | Nickel-Plated Brass | Pack of 5

Sale price$231.46

by Parker Hannifin
Series 23 - Brass/Steel:9123 Coupler with valve, Hose Barb

Package Quantity: 5 Units

Buy More, Save More!
Quantity Price Each
20–29 $217.57
30–59 $196.74
60+ $173.60
Discounts applied in cart/checkout.

Product Data:

Series:
  • 23 Series
Shape:

Straight

Material(s):
  • Nickel-Plated Brass
Series 23 - Brass/Steel Series: Single Shut-Off 1/4" industrial coupling with UltraFlo technology in accordance with ISO 6150 B and US Mil. SPEC 4109. Especially suitable for use with gaseous media in industry. Steel sleeve counters oscillating forces. Special variants with brass valve for use with liquids. High flow performance with low pressure drop and a multitude of connection options.
      Available on request:
  • with additional end connections
  • other seals for different temperature ranges and fluids
Working Pressure:
  • up to 35 bar
Material:
  • Coupling: Nickel-Plated Brass
  • Plug: Nickel-Plated Steel / Brass
  • Seals: NBR
Working Temperature:
  • -20°C up to +100°C (NBR)
Flow Rate Air:
  • 960 l/min. (inlet pressure 6 bar, pressure dop 0.5 bar)
Flow Rate Water:
  • 14 l/min. (pressure drop 0.5 bar)
Part Number A Hex L L1 D
9123 23 08 8 mm 19 mm 74 mm 25 mm 23 mm
9123 23 10 10 mm 19 mm 74 mm 25 mm 23 mm

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
