90CREV6025 Dixon Brass Reversible Concealed Angle Siamese Body - 6" Female NPT Outlet x Two 2-1/2" Female NPT Inlets (Replaces 23-391 Bodies)

90CREV6025 Dixon Brass Reversible Concealed Angle Siamese Body - 6" Female NPT Outlet x Two 2-1/2" Female NPT Inlets (Replaces 23-391 Bodies)

Sale price$1,210.22

Dixon Fire Fittings
Reversible Concealed Angle Siamese Body

Fully reversible with a perpendicular trunnion allowing one body to be installed for top and bottom connections.
Buy More, Save More!
Quantity Price Each
4–7 $1,137.61
8–14 $1,089.20
15+ $968.18
Discounts applied in cart/checkout.

Product Data:

Shape:

90 Degree

Ends Configuration:
  • 6in Female NPT
  • 2-1/2in Female NPT
Material(s):
  • Brass
Features:
  • Maximum operating pressure: 250 PSI at 70°F (21°C).
  • 7-5/8" center.
Back Outlet
-UL listed
-Approved by New York City Board of Standards and Appeals
Part Number Outlet (Two) Inlets Weight
(Lbs.)
4025REV90 4" Female NPT 2-1/2" Female NPT 19.0000
4030REV90 4" Female NPT 3" Female NPT 16.0600
Bottom Outlet
-Replaces 23-391 bodies
Part Number Outlet (Two) Inlets Dimensions Weight
(Lbs.)
A B C
90CREV5025 5" Female NPT 2-1/2" Female NPT - - - N/A
90CREV5030 5" Female NPT 3" Female NPT 12" 9-1/2" 7-5/8" N/A
90CREV6025 6" Female NPT 2-1/2" Female NPT 12" 7-1/4" 7-5/8" N/A
90CREV6030 6" Female NPT 3" Female NPT 12" 9-1/2" 7-5/8" 19.5000

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
