BS087A - #87a Beltservice PVC - 200 Red Supergrip Roughtop x Brushed Conveyor Belt

Buy this Sample or Fill the Form Out Below!

Request a custom quote for Conveyor Belt Assemblies by providing detailed information in the Contact Form below.

Contact Us

Need a Conveyor Belt?

Please provide as much detail you can on your use case and one of our agents will respond ASAP

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
  • Incline/Decline Conveying
  • Packages/Boxes/Cases
Features:
  • Rough textured, non-skid surface enables packages, boxes, cases, and other products to be conveyed on incline or decline.
  • Uni-ply construction and PVC compounds combine all the best properties for high traction conveying and best resistance to oils, greases, water, industrial chemicals, abuse, and stretch.
  • Supergrip is softer durometer for highest grab and steepest inclines.
  • Red No. 87a has outstanding strength and is used extensively in particle board and plywood manufacturing.
PVC - 120 Black
Roughtop x FS
Pt No.: 86		 PVC - 120 Green
Supergrip Roughtop x FS
Pt No.: 87		 PVC - 200 Red
Supergrip Roughtop x Brushed
Pt No.: 87a
Thickness 1/4" 9/32" N/A
Covers Roughtop x FS N/A
Safe Work Load PIW
Conveyor		 100 lbs. 120 lbs. N/A
Safe Work Load PIW
Elevator Allowable		 NR NR N/A
Safe Work Load PIW
Elevator Preferred		 NR NR N/A
Max Bucket Projection
Grain		 NR NR N/A
Max Bucket Projection
Industrial		 NR NR N/A
Min. Pulley Diameter
Conveyor/Elevator		 2-1/2"/NR 3"/NR N/A
Temperature Range 0 deg. F / 180 deg. F N/A
Approx. Weight
Lbs. Per Inch Width		 .089 lbs. .102 lbs. N/A
Clipper Lace #1 #1 N/A
Alligator Lace #7 #7 N/A
Alligator Staple / Flexco SR #125 #125 N/A
FS = Friction Surface
