86330-53-02 by AIGNEP | Ball Valves Series | Ball Valve | 5/32" Tube x 1/8" Male NPTF
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $10.98 |
| 40–79 | $9.93 |
| 80+ | $8.76 |
Discounts applied in cart/checkout.
Product Data:
Series:
Shape:
Straight
Ends Configuration:
Material(s):
Inch Tube x Male
Pressure Rating: Vacuum - 290 PSI
Temperature Range: 0-176° F
Media: Air, oil, water, gas (Consult factory for seal compatability)
Body: Chrome Plated Brass
Thread Type: NPTF
Temperature Range: 0-176° F
Media: Air, oil, water, gas (Consult factory for seal compatability)
Body: Chrome Plated Brass
Thread Type: NPTF
| Product Number | Tube | A NPTF | Color Plate | Thread Type | L | B NPTF IN | B NPTF | Es | C | H | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 86330-53-02 | 5/32" | 1/8" | Composite | NPTF | 35 mm | 0.332" | 8.5 mm | 14 mm | 19 mm | 21 mm | |
| 86330-04-04 | 1/4" | 1/4" | Composite | NPTF | 38.5 mm | 0.488" | 12.5 mm | 14 mm | 19 mm | 21 mm | |
| 86330-06-06 | 3/8" | 3/8" | Composite | NPTF | 45 mm | 0.507" | 13 mm | 18 mm | 19 mm | 22 mm |
