825 by Dixon Valve | Push-In Fitting | Bulkhead Union | 5/32" Tube OD x 7/16"-20 Male NPT | Forged Brass

825 by Dixon Valve | Push-In Fitting | Bulkhead Union | 5/32" Tube OD x 7/16"-20 Male NPT | Forged Brass

Sale price$22.36

Dixon Valve & Coupling
Push-In Fitting | Bulkhead Union | Tube End x Male NPT
Buy More, Save More!
Quantity Price Each
10–39 $21.02
40–79 $19.01
80+ $16.77
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Ends Configuration:
  • 5/32in Push-to-Connect
  • 7/16in Male NPT
Material(s):
  • Brass
Use:
  • Suitable for vacuum service.
  • Working pressure: suitable for use up to the maximum working pressure of the plastic tubing used.
Features:
  • Positive seal: no leaks, after tubing is inserted, seal is made.
  • Secure tube retention: pulling on tubing only serves to tighten the connection.
  • Full flow design provides up to 60% more flow than conventional fittings with internal tube supports.
  • Supplied with gasket.
Construction:
  • Forged Brass
Specifications:
  • Temperature range: -10°F to 200°F (-23°C to 93°C)
Safety Notes:
  • Fittings are suitable for use up to the maximum working pressure of the plastic tubing used.
Installation:
  • Saves up to 75% of assembly time versus the standard compression fittings.
  • Quick connect: simply push tubing in, no tools required.
  • Quick disconnect: hold two fingers on insert and pull tubing out, no tools required.
  • Reusable: connect and disconnect numerous times.
Part Number Tube O.D. Male NPT
824 1/8" 7/16"-20
825 5/32" 7/16"-20
828 1/4" 1/2"-20
8212 3/8" 3/4"-16
8216 1/2" 15/16"-16
