7808 04 14 by Parker | Pneumatic Threshold Sensor | 1/4" Male NPT Thread x 1/4" Female NPT Thread | 5/8" Hex | 2.19" Length | Straight | Nylon

7808 04 14 by Parker | Pneumatic Threshold Sensor | 1/4" Male NPT Thread x 1/4" Female NPT Thread | 5/8" Hex | 2.19" Length | Straight | Nylon

Sale price$56.14

by Parker Hannifin
Threshold Sensor Fittings:7808 - pneumatic threshold sensor 5/32 tube pilot/signal ports to NPT or UNF
Buy More, Save More!
Quantity Price Each
20–39 $52.77
40–79 $47.72
80+ $42.11
Discounts applied in cart/checkout.

Product Data:

Series:
  • 7808 Series
Shape:

Straight

Ends Configuration:
  • 1/4in Male NPT
  • 1/4in Female NPT
Product Features:
  • Glass-reinforced nylon 6.6 body
  • Brass screw
  • NBR seal
  • Silicone-Free
Markets:
  • Factory/Process Automation
  • Packaging
  • Pneumatics
  • Semi-Conductor
Applications:
  • Robotics
  • Packaging
  • Textile
  • Machine Tools
  • Pneumatic Systems
Pressure Range
  • 43.5 to 116 psi (3 to 8 bar)
Temperature Range
  • 5° to 140° F (-15° to 60° C)
Back Pressure
  • 08.5 psi to 1 bar
Response Time
  • 3 ms
Compatible Tubing:
  • Semi-Rigid Nylon
  • Polyurethane 95 Durometer Shore A
  • Fluoropolymer
Part Number NPT / UNF(C) orifice F H J L Oz
7818 04 20* 10-32 .08 5/16" .62" .43" 1.70" .88 Oz
7808 04 11 1/8" .20 9/16" .90" .62" 1.74" 1.55 Oz
7808 04 14 1/4" .27 5/8" 1.09" .76" 1.81" 2.51 Oz
7808 04 18 3/8" .39 7/8" 1.13" .92" 1.91" 3.25 Oz

*10-32: bolt zinc passivated steel
