68VL-12-12 by Parker | Vibra-Lok Fittings | 3/4" Tube Size Connector x 3/4" Male Pipe Thread | 1-3/16" Hex | 2.26" Length | Straight | Brass | Pack of 5
by Parker Hannifin
Vibra-Lok Fittings:Male Connector 68VL
Package Quantity: 5 Units
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $176.18 |
| 20–59 | $159.32 |
| 60+ | $140.57 |
Discounts applied in cart/checkout.
Product Data:
Brand:
Series:
Shape:
Straight
Ends Configuration:
Material(s):
Special Properties:
| Product Features: |
|
|---|---|
| Markets: |
|
| Applications: |
|
| Specification: | |
| Pressure Range: | Dependent on condition and tube size, refer to pressure chart |
 |
|
| Temperature Range: | -15° to +450° F (-26.1° to +232.2° C) with Fluorocarbon Sleeve -30° to +275° F (-34.4° to +135° C) with Buna N Sleeve |
| Compatible Tubing: |
|
 |
||||||
|---|---|---|---|---|---|---|
| Part Number | Tube Size | Pipe Thread | Hex (C) | L | M | Flow Diameter (D) |
| 68VL-2-2 | 1/8" | 1/8" | 7/16" | 1.12" | .81" | .093" |
| 68VL-3-2 | 3/16" | 1/8" | 1/2" | 1.10" | .81" | .125" |
| 68VL-4-2 | 1/4" | 1/8" | 9/16" | 1.15" | .84" | .188" |
| 68VL-4-4 | 1/4" | 1/4" | 9/16" | 1.34" | 1.03" | .188" |
| 68VL-5-4 | 5/16" | 1/4" | 5/8" | 1.41" | 1.06" | .250" |
| 68VL-6-2 | 3/8" | 1/8" | 11/16" | 1.22" | .87" | .235" |
| 68VL-6-4 | 3/8" | 1/4" | 11/16" | 1.41" | 1.06" | .312" |
| 68VL-6-6 | 3/8" | 3/8" | 11/16" | 1.41" | 1.06" | .312" |
| 68VL-8-6 | 1/2" | 3/8" | 7/8" | 1.64" | 1.16" | .406" |
| 68VL-8-8 | 1/2" | 1/2" | 7/8" | 1.64" | 1.35" | .406" |
| 68VL-10-8 | 5/8" | 1/2" | 1-1/16" | 2.10" | 1.44" | .560" |
| 68VL-12-8 | 3/4" | 1/2" | 1-3/16" | 2.26" | 1.50" | .530" |
| 68VL-12-12 | 3/4" | 3/4" | 1-3/16" | 2.26" | 1.50" | .688" |
