66BJB-8G by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Modular Fitting | 1/2" Male BSPP Banjo Bolt x 1/2" Female BSPP Thread | 25mm Hex | 42.0mm Height (H) | Brass | Pack of 10
by Parker Hannifin
Push-to-Connect Fittings:66BJB Female Threaded Banjo Bolt
Package Quantity: 10 Units
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $169.12 |
| 20–59 | $152.92 |
| 60+ | $134.93 |
Discounts applied in cart/checkout.
Product Data:
Series:
Shape:
Banjo
Ends Configuration:
Material(s):
Special Properties:
| Product Features: |
|
|---|---|
| Markets: |
|
| Compatible Media: |
|
| Pressure Range: | Up to 290 PSI (19.9 bar) depending on tubing Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only) |
| Temperature Range: | -4° to +175° F (-20° to +79.4° C) 5° to +155° F (-15° to +68.3° C) (3/16” size only) |
| Vacuum Rating: | 28" Hg |
| Compatible Tubing: |
|
 |
|||||
|---|---|---|---|---|---|
| Part Number | 1 BSPP / M5 | 2 BSPP / M5 | Hex (C) | H | H1 |
| 66BJB-2G | 1/8" | 1/8" | 13 mm | 24.5 mm | 7.5 mm |
| 66BJB-4G | 1/4" | 1/4" | 17 mm | 33.0 mm | 9.5 mm |
| 66BJB-6G | 3/8" | 3/8" | 20 mm | 37.5 mm | 11.0 mm |
| 66BJB-8G | 1/2" | 1/2" | 25 mm | 42.0 mm | 11.5 mm |
*With screwdriver slot
