64183020 (30X20B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 3" Coupler x 2" Male NPT | 316 Stainless Steel | Buna-N Seal
PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | 316 Stainless Steel | Buna-N Seal
Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
Made in the USA
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $290.60 |
| 15–29 | $262.78 |
| 30+ | $231.86 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Cam & Groove Type:
Type B
Ends Configuration:
Material(s):
Seal Material(s):
PRODUCT DESCRIPTION
| Features & Applications: | |||
|---|---|---|---|
|
| Part Name |
Item # | Coupler Size |
Male NPT Threads |
Max. Allowable Working Press. (PSI)* |
|---|---|---|---|---|
| 10X07B | 64181007 | 1" | 3/4" | 250 PSI |
| 10X15B | 64181015** | 1" | 1-1/2" | 250 PSI |
| 15X10B | 64181510** | 1-1/2" | 1" | 250 PSI |
| 20X10B | 64182010** | 2" | 1" | 250 PSI |
| 20X15B | 64182015 | 2" | 1-1/2" | 250 PSI |
| 20X30B | 64182030** | 2" | 3" | 200 PSI |
| 25X20B | 64182520 | 2-1/2" | 2" | 200 PSI |
| 25X30B | 64182530 | 2-1/2" | 3" | 200 PSI |
| 30X20B | 64183020 | 3" | 2" | 200 PSI |
| 30X25B | 64183025 | 3" | 2-1/2" | 200 PSI |
| 30X40B | 64183040** | 3" | 4" | 150 PSI |
| 40X20B | 64184020** | 4" | 2" | 150 PSI |
| 40X30B | 64184030 | 4" | 3" | 150 PSI |
** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
