6300 06 01 24 by Parker | Legris Cartridge | 6mm Tube Size | 11.8mm Length | Brass

6300 06 01 24 by Parker | Legris Cartridge | 6mm Tube Size | 11.8mm Length | Brass

Sale price$10.37

by Parker Hannifin
LIQUIfit® Push-In Fittings / Stud Fittings:6300 Carstick+ Cartridge EPDM
Buy More, Save More!
Quantity Price Each
10–39 $9.75
40–79 $8.81
80+ $8.30
Discounts applied in cart/checkout.
Technical Characteristics:
  • Compatible Fluids: Water, beverages, CO2 (inert use)
  • Working Pressure: Vacuum to 16 bar
  • Working Temperature: -10°C to +95°C
    -20° to +70°C for 16 mm to 10 bar
Advantages:
  • Bio-sourced polymer meeting food process regulations
  • Compliant with FDA, NSF, DM174, KTW, ACS standards
  • Easy-to-clean external surfaces
  • Free of bisphenol and phthalates
Regulations:
  • RoHS
  • REACH
  • FDA: 21 CFR
  • NSF: 51
  • NSF 61 - C HOT
  • 1935/2004
  • DM 174
  • ACS
  • KTW
Component Materials:
  • Body and Adapter: Bio-Based Polymer
  • Grey Release button: Technical Polymer
  • Gripping ring or collet (6501 and 6599): Stainless Steel
  • Seal: EPDM
Pressure and Temperature of the different diameters and related products of the LIQUIfit® Range
Part Number ØD G G1 H L Kg
6300 06 01 24 6 mm 9.9 mm 15.3 mm 11.8 mm 590 mm .002 Kg

50 cartridges per Carstick®

Product Data:

Brand:
  • LIQUIfit®
Series:
  • 6300 Series
Shape:

No Orientation

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
