60181510 (15X10B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 1-1/2" Coupler x 1" Male NPT | Aluminum/HBS | Buna-N Seal
PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | Aluminum/HBS | Buna-N Seal
Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
Made in the USA
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $54.38 |
| 40–79 | $49.17 |
| 80+ | $43.39 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Cam & Groove Type:
Type B
Ends Configuration:
Material(s):
Seal Material(s):
| Features & Applications: | |||
|---|---|---|---|
|
| Part Name |
Item # | Coupler Size |
Male NPT Threads |
Max. Allowable Working Press. (PSI)* |
|---|---|---|---|---|
| 10X20B | 60181020 | 1" | 2" | 200 PSI |
| 15X10B | 60181510 | 1-1/2" | 1" | 250 PSI |
| 15X20B | 60181520 | 1-1/2" | 2" | 250 PSI |
| 20X15B | 60182015 | 2" | 1-1/2" | 250 PSI |
| 20X30B | 60182030 | 2" | 3" | 200 PSI |
| 25X20B | 60182520 | 2-1/2" | 2" | 200 PSI |
| 25X30B | 60182530 | 2-1/2" | 3" | 200 PSI |
| 30X20B | 60183020 | 3" | 2" | 200 PSI |
| 30X25B | 60183025 | 3" | 2-1/2" | 200 PSI |
| 30X40B | 60183040 | 3" | 4" | 150 PSI |
| 40X20B | 60184020 | 4" | 2" | 150 PSI |
| 40X30B | 60184030 | 4" | 3" | 150 PSI |
** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
