6018000004 (25X30B) by PT-Coupling | Reducing Cam & Groove Adapter | Type B | 2-1/2" Coupler x 3" Male NPT | Aluminum/HB | Buna-N Seal
PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type B | Adapter x Male NPT | Aluminum/HB | Buna-N Seal
Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
Made in the USA
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $85.32 |
| 20–59 | $77.15 |
| 60+ | $68.08 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Cam & Groove Type:
Type B
Ends Configuration:
Material(s):
Seal Material(s):
| Features & Applications: | |||
|---|---|---|---|
|
| Part Name |
Item # | Coupler Size |
Male NPT Threads |
Max. Allowable Working Press. (PSI)* |
|---|---|---|---|---|
| 15X10B | 6018000009 | 1-1/2" | 1" | 250 PSI |
| 20X15B | 6018000001 | 2" | 1-1/2" | 250 PSI |
| 20X30B | 6018000002 | 2" | 3" | 200 PSI |
| 25X20B | 6018000003 | 2-1/2" | 2" | 200 PSI |
| 25X30B | 6018000004 | 2-1/2" | 3" | 200 PSI |
| 30X20B | 6018000005 | 3" | 2" | 200 PSI |
| 30X25B | 6018000006 | 3" | 2-1/2" | 200 PSI |
| 30X40B | 6018000103 | 3" | 4" | 150 PSI |
| 40X20B | 6018000007 | 4" | 2" | 150 PSI |
| 40X30B | 6018000008 | 4" | 3" | 150 PSI |
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
