60142520 (25X20A) by PT-Coupling | Reducing Cam & Groove Adapter | Type A | 2-1/2" Adapter x 2" Female NPT | Aluminum
PT Coupling
Reducing Cam & Groove (Camlock) Adapter | Type A | Adapter x Female NPT | Aluminum
Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
Made in the USA
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $67.64 |
| 40–79 | $61.17 |
| 80+ | $53.97 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Cam & Groove Type:
Type A
Ends Configuration:
Material(s):
| Features & Applications: | |||
|---|---|---|---|
|
| Part Name |
Item # | Adapter Size |
Female NPT Threads |
Max. Allowable Working Press. (PSI)* |
|---|---|---|---|---|
| 07X10A | 60220710 | 3/4" | 1" | 250 PSI |
| 10X15A | 60141015 | 1" | 1-1/2" | 250 PSI |
| 15X10A | 60141510 | 1-1/2" | 1" | 250 PSI |
| 15X20A | 60141520 | 1-1/2" | 2" | 250 PSI |
| 20X15A | 60142015 | 2" | 1-1/2" | 250 PSI |
| 20X25A | 60142025 | 2" | 2-1/2" | 200 PSI |
| 20X30A | 60142030 | 2" | 3" | 200 PSI |
| 25X15A | 60142515 | 2-1/2" | 1-1/2" | 200 PSI |
| 25X20A | 60142520 | 2-1/2" | 2" | 200 PSI |
| 25X30A | 60142530 | 2-1/2" | 3" | 200 PSI |
| 25X40A | 60142540 | 2-1/2" | 4" | 150 PSI |
| 30X20A | 60143020 | 3" | 2" | 200 PSI |
| 30X25A | 60143025 | 3" | 2-1/2" | 200 PSI |
| 30X40A | 60143040 | 3" | 4" | 150 PSI |
| 40X25A | 60144025 | 4" | 2-1/2" | 150 PSI |
| 40X30A | 60144030 | 4" | 3" | 150 PSI |
| 40X50A | 60144050 | 4" | 5" | 75 PSI |
| 50X30A | 60145030 | 5" | 3" | 75 PSI |
** Denotes parts are produced as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
