5750808K by Dixon Valve | Lok-On (Push-On) Garden Hose Fitting Complete Set | 3/4" Female GHT x 3/4" Male GHT x 1/2" Hose ID | Brass

5750808K by Dixon Valve | Lok-On (Push-On) Garden Hose Fitting Complete Set | 3/4" Female GHT x 3/4" Male GHT x 1/2" Hose ID | Brass

Sale price$25.55

Dixon Valve
Lok-On (Push-On) Garden Hose Fitting Complete Set | Female GHT x Male GHT x Hose Barb

Intended for use with Lok-On (push-on style) hose only.
Buy More, Save More!
Quantity Price Each
10–39 $24.02
40–79 $21.72
80+ $19.16
Discounts applied in cart/checkout.

Product Data:

Series:
  • 575 Series
Shape:

Straight

Ends Configuration:
  • 3/4in Male GHT
  • 3/4in Female GHT
  • 1/2in Push-On Hose Barb
Features:
  • No hose clamps or ferrules are needed for installation.
  • Properly grips push-on hose only when pushed all the way in, with the cut end of the hose completely concealed by the plastic cap.
  • Not assembled.
Material:
  • Brass
  • Yellow Plastic Cap
  • Washer included
Specifications:
  • Temperature Range: 34°F to 150°F
  • Pressure Rating: 150 PSI
Safety Notes:
  • Dixon push-on fittings are intended for use with Lok-On (push-on style) hose only.
  • Caution: Push-on fittings will properly grip push-on hose only when pushed all the way in, with the cut end of the hose completely concealed by the plastic cap.
Installation:
  • Assembly Instructions:
    • 1. Trim hose end with smooth square cut.
    • 2. Lubricate either push-on fitting, hose or both.
    • 3. Insert push-on fitting into hose until first barb is in hose.
    • 4. Place end of fitting against a flat object (bench, wall, etc.) and grip the hose one inch from end. Push with a steady force until end of hose is covered by yellow plastic cap.
  • Disassembly Instructions:
    • 1. Leaving push-on fitting in place, make a 1" cut in the hose along the barbed end of the fitting. Note: Be careful not to nick barbs when cutting the hose.
    • 2. With firm grip on hose, give a sharp downward pull to release the fitting from the hose.
Part Number Previous Part Number Hose I.D. Female GHT x Male GHT Thread
5750808K 575-0808 1/2" 3/4"
5751010K 575-1010 5/8" 3/4"
5751212K 575-1212 3/4" 3/4"
