5260550 by Fenner Drives | Eagle Hyfen 85 CXF V Belting | Cross Section D | 1.25" w x 0.85" h | Reinforced | Blue, Green, Orange | 100ft

5260550 by Fenner Drives | Eagle Hyfen 85 CXF V Belting | Cross Section D | 1.25" w x 0.85" h | Reinforced | Blue, Green, Orange | 100ft

Sale price$4,803.95
Fenner Drives - Conveying - V Belting - Reinforced

Package Quantity: 100 FT

Buy More, Save More!
Quantity Price Each
2–3 $4,515.71
4–9 $4,323.56
10+ $3,843.16
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Eagle
Series:
  • 85 Series
Overview:
  • Eagle Hyfen 85 Reinforced CXF Vee Belting is a co-extruded belt constructed of a polyester reinforced 85 A durometer polyurethane base belt and a softer, higher CoF (coefficient of friction) 60 A durometer polyurethane top surface. Packaged in 100'/30.5m lengths.
Description:
  • Fenner Drives unique dual durometer belts offer strength and load carrying capabilities with the added bonus of the ultra-grip tops. The combination of a tough 85A durometer base and an ultra-grip co-extruded 60A top surface gives you the strength and grip that your demanding application needs! In addition to the already reliant durability of this belt, there is also a polyester reinforcing tensile member to increase the strength of the belt.

    Best Suited For: Conveying applications that require an extremely strong, low stretch vee belt combined with a high traction surface. Perfectly suited for carrying heavy loads up an inclined conveyor.

  • 85A polyurethane base durometer
  • 60A co-extruded unltra-grip top surface
  • Strength and load carrying capabilities
  • Polyester reinforcing tensile membert
  • RoHS 2002/95/EC Directive Compliant


    • This CXF belt has a flat top surface providing you with the extra grip you need for your application. Our integrally bonded tops cannot delaminate leaving you worry and stress free! Fenner Drives Eagle Co-Extruded belting easily outperforms all adhesively bonded special surface belts!

    Eagle Hyfen 85 Reinforced CXF Vee Belts are easily welded endless in the field with either a Fenner Drives Butt Welding Kit or for the strongest weld possible, a Fenner Drives Overlap Welding Kit.

    Since Eagle Eagle Hyfen 85 Reinforced CXF Vee Belts are not self-tensioning, they work perfectly with Fenner Drives' own T-Max Automatic Belt Tensioners.

SPECIFICATIONS

Profile Shape: Twin, Vee Profile Size: A/13, B/17, C/22, D/32
Reinforcement: Polyester Tape Color: Blue, Green, Orange
Compliancy: RoHS Durometer: 60A, 85A
Material: Polyurethane Special Feature: Smooth Ultra-Grip 60A Top Surface Package Length: 100'/30.5m

Part Number Material & Color Cross Section Dimensions
w x h*		 Minimum Pulley Ø Working Load @ Percent Tension Weight
4% 6% 8% 10%
in mm in mm lbs N lbs N lbs N lbs N lbs/ft kg/m
5260550 Eagle Hyfen 85 CXF D 1.25 x 0.85" --- 10.88" 276mm 77.1 343 111 493.6 149.5 665 189.4 842.4 0.448 lbs 0.667 kg

* w (width) is the widest part of the belt. h (height) is the tallest part of the belt, including the belting top surface. Dimensions are for reference only.

Fenner Drives

Fenner Drives is a leading manufacturer of products for power transmission, motion transfer, and conveying applications. We consistently blend reliability, quality, and value across our entire product portfolio, which includes tensioners, pulleys and idlers, and bearings.
