5/8" R17 by Couplamatic | Import 3000 PSI | Two Wire Hydraulic Hose | SAE 100R17 | Reduced OD | 5/8" ID | 250ft
Couplamatic Systems Inc.
One or Two Wire Braids Hoses - R17 Import 3000 PSI Constant Working Pressure Hydraulic Hose - (SAE 100R17) (Reduced OD)
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $1,026.42 |
| 8–14 | $982.75 |
| 15+ | $873.55 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
3000
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R17 |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | One (1/4"-1/2") or Two (5/8"-1") Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" R17 | 1/4" | 0.492" | 3,000 lbs. | 12,000 lbs. | 2" | 13 lbs. | 500ft |
| 3/8" R17 | 3/8" | 0.649" | 3,000 lbs. | 12,000 lbs. | 3" | 19 lbs. | 500ft |
| 1/2" R17 | 1/2" | 0.776" | 3,000 lbs. | 12,000 lbs. | 4" | 31 lbs. | 350ft |
| 5/8" R17 | 5/8" | 0.937" | 3,000 lbs. | 12,000 lbs. | 4" | 41 lbs. | 250ft |
| 3/4" R17 | 3/4" | 1.090" | 3,000 lbs. | 12,000 lbs. | 5" | 53 lbs. | 250ft |
| 1" R17 | 1" | 1.405" | 3,000 lbs. | 12,000 lbs. | 6" | 82 lbs. | 200ft |
