4928001 by Fenner Drives | Eagle 80 EC Round Belting | 3mm Diameter | Non-Reinforced | Blue | 100ft
Fenner Drives

4928001 by Fenner Drives | Eagle 80 EC Round Belting | 3mm Diameter | Non-Reinforced | Blue | 100ft

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

Overview:
  • Eagle Blue 80 EC Non-Reinforced Round Belting is made of solid polyurethane designed specifically for direct food contact within the framework defined by the Regulation 1935/2004/EC. Also offers excellent abrasion resistance and high elasticity. Packaged in 100'/30.5m lengths.
Description:
  • Eagle Blue 80 EC Non-Reinforced Round Belting is Fenner Drives' latest addition to the already stellar Eagle line. This Eagle premium belt is suitable for repeat use direct food contact at temperatures up to 40 deg. C (104 deg.F) with all food types having a pH of greater than 4.5.

    Independently certified to meet the requirements of European Regulation 10/2011 (and the legislation which it replaces; Commission Directive 2002/72/EC) within the framework defined by the Regulation 1935/2004/EC (27/10/2004) relating to plastic materials and articles intended to come into direct contact with foodstuffs.

    When used in a range of "typical" process environments, Eagle EC belting will not allow components to migrate into food in quantities that could endanger human health, change the composition of the food in an unacceptable way or deteriorate the taste and smell of foodstuffs.

    80 Shore A durometer polyurethane belting Eagle premium belting for repeated direct food contact Independently tested and verified to meet FDA standards for direct food contact For repeat use food contact at temps up to 40 deg. C with all types having a pH greater than 4.5. Solid polyurethane construction Produced in accordance with Good Manufacturing Practice (GMP) standards with exacting quality control, Eagle EC Belting is of such dimensional consistency sanitary conveyor system performance and reliability is improved.

    Eagle Blue EC Non-Reinforced Round Belts are easily welded endless in the field with a Fenner Drives Butt Welding Kit.

SPECIFICATIONS

Profile Shape: Round Profile Size: 10mm, 8mm, 9.5mm
Reinforcement: None Color: Blue
Compliancy: EC Food Safety, FDA, REACH, RoHS Durometer: 80A
Material: Polyurethane Package Length: 100'/30.5m

Part Number Material & Color Dimensions Ø Minimum Pulley Ø Working Load @ Percent Tension Weight
4% 6% 8% 10%
in mm in mm lbs N lbs N lbs N lbs N lbs/ft kg/m
L04OP802M Eagle Opaque 80 --- 2mm 0.63" 16mm 0.2 0.9 0.3 1.3 0.4 1.8 0.5 2.2 0.003 lbs 0.004 kg
L04OG852M Eagle Orange 85 --- 2mm 0.63" 16mm 0.2 0.9 0.3 1.3 0.4 1.8 0.5 2.2 0.003 lbs 0.004 kg
L04C852M Eagle Clear 85 --- 2mm 0.63" 16mm 0.2 0.9 0.3 1.3 0.4 1.8 0.5 2.2 0.003 lbs 0.004 kg
4905402 Eagle Green 89 --- 2mm 0.71" 18mm 0.3 1.4 0.5 2.4 0.7 3.2 0.9 4 0.003 lbs 0.004 kg
4905302 Eagle Green 89 Textured --- 2mm 0.71" 18mm 0.2 1 0.4 1.7 0.5 2.3 0.7 2.9 0.003 lbs 0.004 kg
4940017 Eagle Red 90 --- 2mm 0.79" 20mm 1.1 4.7 1.5 6.8 1.9 8.5 2.2 10 0.003 lbs 0.004 kg
1032003 Eagle Orange 85 3/32" --- 0.75" 19mm 0.3 1.2 0.4 1.9 0.6 2.5 0.7 3.1 0.004 lbs 0.005 kg
4908003 Eagle Clear 85 3/32" --- 0.75" 19mm 0.3 1.2 0.4 1.9 0.6 2.5 0.7 3.1 0.004 lbs 0.005 kg
4907003 Eagle Clear 95 3/32" --- 0.94" 24mm 0.5 2.3 0.8 3.4 1 4.3 1.2 5.1 0.004 lbs 0.005 kg
1032004 Eagle Orange 85 1/8" --- 1" 25mm 0.5 2.2 0.7 3.3 1 4.4 1.2 5.5 0.006 lbs 0.01 kg
4908006 Eagle Clear 85 1/8" --- 1" 25mm 0.5 2.2 0.7 3.3 1 4.4 1.2 5.5 0.006 lbs 0.01 kg
4907006 Eagle Clear 95 1/8" --- 1.25" 32mm 0.9 4 1.3 6 1.7 7.7 2.1 9.1 0.007 lbs 0.01 kg
4928001 Eagle Blue 80 EC --- 3mm 0.83" 21mm 0.4 1.7 0.6 2.5 0.8 3.5 1 4.3 0.005 lbs 0.008 kg
4927001 Eagle Cear 80 EC --- 3mm 0.83" 21mm 0.4 1.7 0.6 2.5 0.8 3.5 1 4.3 0.005 lbs 0.008 kg
L04OP803M Eagle Opaque 80 --- 3mm 0.83" 21mm 0.5 2.1 0.8 3.5 1.1 4.9 1.4 6.2 0.006 lbs 0.009 kg
L04OG853M Eagle Orange 85 --- 3mm 0.94" 24mm 0.4 1.9 0.7 3 0.9 4 1.1 4.9 0.006 lbs 0.009 kg
L04C853M Eagle Clear 85 --- 3mm 0.94" 24mm 0.4 1.9 0.7 3 0.9 4 1.1 4.9 0.006 lbs 0.009 kg
L04BL853M Eagle Blue 85 --- 3mm 0.94" 24mm 0.4 1.9 0.7 3 0.9 4 1.1 4.9 0.006 lbs 0.009 kg
L04G893MS Eagle Green 89 --- 3mm 1.06" 27mm 0.7 3.2 1.2 5.2 1.6 7.2 2 9 0.006 lbs 0.009 kg
4905303 Eagle Green 89 Textured --- 3mm 1.06" 27mm 0.5 2.3 0.9 3.8 1.2 5.2 1.5 6.5 0.006 lbs 0.009 kg
4940020 Eagle Red 90 --- 3mm 1.18" 30mm 2.4 10.5 3.4 15.1 4.3 19 5 22.2 0.006 lbs 0.009 kg
