4735-0150-100ERNPS by Jason Industrial | 4735 Series | MSHA Fire Hose Assembly | 300 PSI Serv. Press. | 1-1/2" ID | NPS EXP Ring | White | 100ft

4735-0150-100ERNPS by Jason Industrial | 4735 Series | MSHA Fire Hose Assembly | 300 PSI Serv. Press. | 1-1/2" ID | NPS EXP Ring | White | 100ft

Sale price$527.54

Jason Industrial Inc. Hose - Water Hose - 4735 MSHA Fire Hose Assembly - White

Package Quantity: 100 FT

Buy More, Save More!
Quantity Price Each
5–14 $495.89
15–29 $448.41
30+ $422.03
Discounts applied in cart/checkout.

SPECIFICATIONS

Application: Underground mining fire hose. SAE Rating: N/A
Other Ratings: MSHA rating 18-FHA08001 Tube: Chloroprene (CR)
Reinforcement: N/A Cover: Polyester
Temperature Range: -25 deg F (-32 deg. C) to +185 deg. F (+85 deg. C) Crimp Fittings: N/A
Reusable Fittings: N/A Branding: Jason logo 300 PSI Test, MSHA #18-FHA08001
Other Features:
  • Meets MSHA rating 18-FHA08001, therefore resistant to fire.
  • Rolls flat for easy storage
  • Couplings are anodized aluminum M x F expansion ring with rocker lugs
  • 100% polyester jacket, which is free from defects, twists, knots and irregularities
Part Number I.D. Coupling Reinforcement Plies Service Pressure Test Pressure Vacuum @ 68 deg. F Weight Standard Length
in. mm PSI BAR PSI BAR inHg lb./ft. KG/m ft
Coupled
4735-0150-050ERNPS 1-1/2" 38.10mm Male NPS x Female NPS Expansion Ring with Rocker Lug N/A 300 PSI 20.68 BAR 900 PSI 62.04 BAR N/A 0.23 lb./ft. 0.34 KG/m 50ft
4735-0150-050ERNST 1-1/2" 38.10mm Male NST x Female NST Expansion Ring with Rocker Lug N/A 300 PSI 20.68 BAR 900 PSI 62.04 BAR N/A 0.23 lb./ft. 0.34 KG/m 50ft
4735-0150-100ERNPS 1-1/2" 38.10mm Male NPS x Female NPS Expansion Ring with Rocker Lug N/A 300 PSI 20.68 BAR 900 PSI 62.04 BAR N/A 0.23 lb./ft. 0.34 KG/m 100ft
Working pressure is temperature dependent. Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.

Product Data:

Series:
  • 4735 Series
Color(s):
  • White/Off-White
Internal Diameter:
  • 1.50in

Jason Industrial

Founded in 1958 in Fairfield, NJ, Jason Industrial quickly gained a solid reputation as a go to source for both industrial hose and power transmission belts. Jason Industrial offers a comprehensive portfolio of industrial hose, couplings and accessories along with hydraulic hose, fittings and crimping equipment.
