BS046 - #46 Beltservice 3 Ply Hot Stock and Water HSW Conveyor Belt
BS046 - #46 Beltservice 3 Ply Hot Stock and Water HSW Conveyor Belt
Beltservice

BS046 - #46 Beltservice 3 Ply Hot Stock and Water HSW Conveyor Belt

Buy this Sample or Fill the Form Out Below!

Request a custom quote for Conveyor Belt Assemblies by providing detailed information in the Contact Form below.

Contact Us

Need a Conveyor Belt?

Please provide as much detail you can on your use case and one of our agents will respond ASAP

$10.00 IS FOR A PRODUCT SAMPLE
-or-
REQUEST A FREE BELT ASSEMBLY QUOTE

Use [Add to cart] to purchase a sample piece of belting which will put a $10 credit on your account if you decide to order your belt from BeltSmart. Limit 3 per customer or $30.00 total. Product samples are shipped priority mail.

Use [Request a Laced or Endless Belt Quote] to have our customer service work up a quote with mechanical lace, open-ended, or vulcanized endless. Our team of belt specialists are on hand during regular business hours to answer questions and help with any questions you may have.

If you are unsure what your belting is and would like us to identify it, please send us a sample of the belting to the address given in our [about us] page. Include name, company, phone, address and dimensions to 1/8" for width and length.

Applications:
  • Slider bed
  • Deflector bar applications
  • "Stall" operations
  • Uncured rubber
  • Tire plants
Features:
  • Bare duck surface down for lowest possible friction for slider bed use, and up for deflector bar applications; ideal as slip-top belt for "stall" operations.
  • Its true use is for conveying uncured rubber in tire plants.
3 Ply Hot Stock and Water
Pt No.: 46
Thickness 9/64"
Covers White Bare Duck x FS
Carcass 2-28 oz. Cotton
1-35 oz. HSD
Working Tension
per Inch Width		 90 lbs.
Approx. Weight
Lbs. Per Inch Width		 .071 lbs.
Min. Pulley Diameter 2-1/2"
Temperature Range -40 deg. F / 250 deg. F
Clipper Lace #2
Alligator Lace #15
Flexco Hinged NA
Alligator Staple #125
FS = Friction Surface

BeltService

Beltservice Corporation is a family-owned company where employees learn, grow and meaningfully contribute to the continued and shared company success. As America's largest wholesaler and fabricator of industrial conveyor belting, Beltservice Corporation values the talent and ambition of employees at every level and capacity throughout the organization.
