4202 40 49 20 by Parker | Axial Valve | G1-1/2" Female BSPP Thread w/ FKM Seal | 181mm Length | Straight | Nickel-Plated Brass

4202 40 49 20 by Parker | Axial Valve | G1-1/2" Female BSPP Thread w/ FKM Seal | 181mm Length | Straight | Nickel-Plated Brass

Sale price$664.54

by Parker Hannifin
Axial Valves:4202 Normally Closed Axial Valve with FKM Seal, Female BSPP Thread Nickel-plated brass, FKM
Buy More, Save More!
Quantity Price Each
5–14 $624.67
15–29 $564.86
30+ $498.41
Discounts applied in cart/checkout.

Product Data:

Series:
  • 4202 Series
Shape:

Straight

Ends Configuration:
  • 1-1/2in Female BSPP
  • 1-1/2in Female BSPP
  • Some Ends Match
This valve is equipped with a pneumatic or electro-pneumatic actuator, so it can be integrated into simple automated systems.
Product Features:
  • Very compact
  • Simple to install: ready-to-use
  • Two seal materials (FKM, EPDM) for a wider chemical and temperature range
  • Pneumatic or electro-pneumatic
  • Three versions: normally closed, normally open and double-acting
Applications:
  • Injection Molding
  • Pneumatics
  • Packaging
  • Textile
  • Printing
  • Robotics
Compatible Fluids:
  • Compressed air, water, industrial fluids
  • Other fluids: please contact division.
Specification:
Temperature Range:
  • -4° to +275°F (-20° to +150°C) (suffix 20 FKM)
  • -4° to +275°F (-20° to +150°C) ((suffix 30 EPDM optional; please contact division)
Pressure Range:
  • Up to 150 PSI (10.3 bar)
Vacuum Service:
  • 29 in Hg
Pilot Pressure:
  • NC and NO: 61 to 116 PSI (4.2 to 8 bar)
  • Double-acting: 62 to 116 PSI (4.3 to 8 bar)
Part Number BSSP (C) F G H H1 L Kg.
4202 10 17 20 G1/8" 22 mm 46 mm 53.5 mm 30.5 mm 98 mm .65 Kg
4202 15 21 20 G1/2" 27 mm 52 mm 59.0 mm 33.0 mm 113 mm .85 Kg
4202 20 27 20 G3/4" 33 mm 63.5 mm 71.0 mm 39.0 mm 136 mm 1.50 Kg
4202 25 34 20 G1" 41 mm 69 mm 76.0 mm 41.5 mm 144 mm 1.70 Kg
4202 32 42 20* G1-1/4" 50 mm 86 mm 91.0 mm 48.0 mm 166 mm 3.30 Kg
4202 40 49 20* G1-1/2" 60 mm 96 mm 102.0 mm 54.0 mm 181 mm 3.60 Kg
4202 50 48 20* G2" 70 mm 109 mm 115.0 mm 60.0 mm 205 mm 5.10 Kg

Pilot port: G1/8

Delivered with a silencer

*Models with EC marking
