3S-H-15U-GFBTSS Dixon Stainless Steel Bottom Mount Sanitary Pressure Gauge - 3-1/2" Dial Size - 1-1/2" Clamp Size - 0-400 PSI Range
Dixon

3S-H-15U-GFBTSS Dixon Stainless Steel Bottom Mount Sanitary Pressure Gauge - 3-1/2" Dial Size - 1-1/2" Clamp Size - 0-400 PSI Range

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

Features:
  • Accuracy: ± 1.5% of full scale
  • Over range capacity: 30%
  • Wetted surfaces: 316L stainless steel
  • Surface finishes (wetted parts): Ra max = 25 microinches
  • Case material: 304 stainless steel
  • Dial size: 3-1/2"
  • Lens material: polycarbonate
  • Temperature range: 0°F (-18°C) to 250°F (121°C)
  • Standard fill: food grade glycerin
  • Rezero feature: standard on pointer
Part Number Dial Size Clamp Size Pressure Range
(PSI)		 Fill Mount
3S-H-15U-GFBTSS 3-1/2" 1-1/2" 0-400 PSI Glycerin Bottom Mount
3S-H-2U-GFBTSS 3-1/2" 2" 0-400 PSI Glycerin Bottom Mount
3S-HB-25U-GFLTS 3-1/2" 2-1/2" 0-400 PSI / 0-28 Bar Range Glycerin Left Mount
3S-HB-25U-GFRTS 3-1/2" 2-1/2" 0-400 PSI / 0-28 Bar Range Glycerin Right Mount
