3S-BB-15U-GFBTS Dixon Stainless Steel Bottom Mount Sanitary Pressure Gauge - 3-1/2" Dial Size - 1-1/2" Clamp Size - 0-30 PSI / 0-2 Bar Range
Dixon Sanitary Pressure Gauges
3-1/2" Gauge - 0-30 PSI Range - Stainless Steel
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $790.58 |
| 15–29 | $714.88 |
| 30+ | $630.78 |
Discounts applied in cart/checkout.
Product Data:
| Features: | |||
|---|---|---|---|
|
 |
|||||
|---|---|---|---|---|---|
| Part Number | Dial Size | Clamp Size | Pressure Range (PSI) |
Fill | Mount |
| 3S-B-15U-GFBKSS | 3-1/2" | 1-1/2" | 0-30 PSI | Glycerin | Back Mount |
| 3S-B-15U-GFBTSS | 3-1/2" | 1-1/2" | 0-30 PSI | Glycerin | Bottom Mount |
| 3S-B-15U-GFLFSS | 3-1/2" | 1-1/2" | 0-30 PSI | Glycerin | Left Mount |
| 3S-B-15U-GFRTSS | 3-1/2" | 1-1/2" | 0-30 PSI | Glycerin | Right Mount |
| 3S-B-15U-NFBTS | 3-1/2" | 1-1/2" | 0-30 PSI | No Fill | Bottom Mount |
| 3S-B-25U-GFBTSS | 3-1/2" | 2-1/2" | 0-30 PSI | Glycerin | Bottom Mount |
| 3S-B-2U-GFBKSS | 3-1/2" | 2" | 0-30 PSI | Glycerin | Back Mount |
| 3S-B-2U-GFBTSS | 3-1/2" | 2" | 0-30 PSI | Glycerin | Bottom Mount |
| 3S-B-2U-NFBTS | 3-1/2" | 2" | 0-30 PSI | No Fill | Bottom Mount |
|
3S-B-2UGFBTSSF (with-Flo-Dry-Logo) |
3-1/2" | 2" | 0-30 PSI | Glycerin | Bottom Mount |
| 3S-BB-15U-GFBTS | 3-1/2" | 1-1/2" | 0-30 PSI / 0-2 Bar | Glycerin | Bottom Mount |
