39900-2523 by Garlock | Style 9900 | 0.063in Thick | 60in x 120in

Benefits:
Tough & Reliable Graphite fiber gasketing withstands extreme temperatures and pressures, as well as many chemicals Passed Garlock fire tests and is ABS Fire Safe Type Approved See note below for STR 508
Tighter Seal:
Maintains superior seal during thermal cycling, even in saturated steam† and hot oils Significantly reduces emissions to meet stringent Clean Air Act requirements
Easy to Install:
Graphite fiber sheet is easier to handle and cut than exfoliated graphite sheets or metal-inserted gasket material
Media:
Saturated steam†, water, inert gases, aliphatic hydrocarbons, oils, gasoline and most refrigerants

Typical Physical Properties

		99004	98004	98504
Color		Mahogany	Black	Black
Composition		Graphite with nitrile	Carbon with SBR	Carbon with nitrile
Temperature1	Maximum Minimum Continuous Max.	1,000°F (540°C) -100°F (-75°C) 650°F (340°C)	900°F (480°C) -100°F (-75°C) 650°F (340°C)	900°F (480°C) -100°F (-75°C) 650°F (340°C)
Pressure1 Continuous Max.	psig (bar)	2,000 (138)	2,000 (138)	2,000 (138)
P x T, max. (psig x °F) (bar x °C)	1/32", 1/16" (0.8mm, 1.6mm) 1/8" (3.2mm)	700,000 (25,000) 350,000 (12,000)	700,000 (25,000) 350,000 (12,000)	700,000 (25,000) 350,000 (12,000)
Sealability (ASTM F37B)2 ASTM Fuel A Nitrogen	ml/hr ml/hr	0.3 0.6	0.3 0.6	0.3 0.6
Creep Relaxation (ASTM F38)(1/32")	%	9	15	15
Compressibility Average (ASTM F36)	%	9	8	8
Recovery (ASTM F36)	%	>55	>55	>55
Tensile Strength across grain (ASTM F152)	psi (N/mm2)	1,800 (12)	1,800 (10)	1,800 (12)
Density	lbs/ft3 (g/cm3)	110 (1.76)	105 (1.68)	105 (1.68)
Gas Permeability (DIN 3535 Part 4)3	cc/min.	0.015	0.015	0.015

Order Code (Part Number)	Style	Thickness (in.)	Width (in.)	Length (in.)
39900-2438	9900	0.016"	60"	60"
39900-2440	9900	0.016"	60"	120"
39900-2801	9900	0.016"	60"	180"
39900-2480	9900	0.031"	60"	60"
39900-2482	9900	0.031"	60"	120"
39900-2802	9900	0.031"	60"	180"
39900-2501	9900	0.047"	60"	60"
39900-2503	9900	0.047"	60"	120"
39900-2803	9900	0.047"	60"	180"
39900-2521	9900	0.063"	60"	60"
39900-2523	9900	0.063"	60"	120"
39900-2804	9900	0.063"	60"	180"
39900-2563	9900	0.094"	60"	60"
39900-2565	9900	0.094"	60"	120"
39900-2806	9900	0.094"	60"	180"
39900-2605	9900	0.125"	60"	60"
39900-2607	9900	0.125"	60"	120"
39900-2808	9900	0.125"	60"	180"

This is a general guide and should not be the sole means of selecting or rejecting this material. ASTM test results in accordance with ASTM F-104; properties based on 1/16" (1.6mm) sheet thickness.
* Values do not constitute specification limits All styles are furnished with an anti-stick parting agent as standard.

¹ Based on ANSI RF flanges at our preferred torque. When approaching maximum pressure, continuous operating temperature, minimum temperature or 50% of maximum PxT, consult Garlock Engineering.
² ASTM F37B Sealability
ASTM Fuel A (isooctane):
- Gasket load = 500 psi (3.5 N/mm2), Int. pressure = 9.8 psig (0.7 bar)
Nitrogen:
- Gasket load = 3,000 psi (20.7 N/mm2), Int. pressure = 30 psig (2 bar)
³ DIN 3535 Part 4 Gas Permeability, cc/min. (1/16" thick)
Nitrogen:
- Gasket load = 4,640 psi (32 N/mm2), Int. pressure = 580 psig (40 bar)
⁴ Saturated steam service guidelines:
> For optimal performance, use thinner gaskets when possible.
> Minimum recommended assembly stress = 4,800 psi.
> Preferred assembly stress = 6,000 psi to 10,000 psi.
> Retorque the bolts/studs prior to pressurizing the assembly.
> If the service is superheated steam, contact Applications Engineering.
