365PLP-4M-6M by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Tube to Tube Fittings | 4mm to 6mm Unequal Union | 22.5mm Length (L) | 90° Elbow | Glass-Reinforced Nylon | Pack of 10

365PLP-4M-6M by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Tube to Tube Fittings | 4mm to 6mm Unequal Union | 22.5mm Length (L) | 90° Elbow | Glass-Reinforced Nylon | Pack of 10

Sale price$49.57

by Parker Hannifin
Push-to-Connect Fittings:365PLP Unequal Union Elbow

Package Quantity: 10 Units

Buy More, Save More!
Quantity Price Each
10–39 $46.60
40–79 $42.13
80+ $37.18
Discounts applied in cart/checkout.

Product Data:

Series:
  • 365PLP Series
Shape:

90° Elbow

Ends Configuration:
  • 4mm Push-to-Connect
  • 6mm Push-to-Connect
Product Features:
  • Stainless steel grab ring
  • Glass-reinforced nylon 6.6 body
  • Nitrile D-seal
  • Nylon release button
  • Corrosion and chemical resistance
  • NPT, BSPT, BSPP, and metric threads
  • Silicone Free
Markets:
  • Pneumatic
  • Industrial
  • Robotic
  • Automation
  • Printing
  • Packaging
  • Textile
Compatible Media:
  • Compressed Air
  • Inert Gases
  • Vacuum
Pressure Range: Up to 290 PSI (19.9 bar) depending on tubing
Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only)
Temperature Range: -4° to +175° F (-20° to +79.4° C)
5° to +155° F (-15° to +68.3° C) (3/16” size only)
Vacuum Rating: 28" Hg
Compatible Tubing:
  • Semi-rigid nylon
  • Polyurethane 95 Durometer Shore A*
  • Nylon
  • Fluoropolymer
  • Polyethylene
Part Number Tube Size 1 Tube Size 2 L
365PLP-4M-6M 4 mm 6 mm 22.5 mm
365PLP-6M-8M 6 mm 8 mm 29.5 mm
365PLP-8M-10M 8 mm 10 mm 34.5 mm
365PLP-10M-12M 10 mm 12 mm 40.5 mm
