3381 06 00 by Parker | Legris Modular Plug-In Connectors | 6mm Tube Size | 39.5mm Length | Straight | Polymer | Pack of 5

3381 06 00 by Parker | Legris Modular Plug-In Connectors | 6mm Tube Size | 39.5mm Length | Straight | Polymer | Pack of 5

Sale price$149.08

Package Quantity: 5 Units

Buy more, save moreDiscounts applied in cart/checkout.
Technical Characteristics:
  • Compatible Fluids: Compressed air
  • Working Pressure: Vacuum to 10 bar
  • Working Temperature: -20°C to +80°C
Advantages:
  • 3 types of solutions: in-line, panel-mounted or DIN rail connector
  • Minimized connection space
  • Prevents incorrect assembly
  • Customized multi-connectors upon request
Regulations:
  • ISO 14743
  • PED
  • RoHS
  • REACH
Component Materials:
  • Panel-mounted: Zinc-Plated Steel, Technical Polymer
  • In-Line: Aluminum, Technical Polymer
  • DIN Rail: Technical Polymer
Part Number ØD H K L N Kg
3381 04 00 4 mm 36.5 mm 11 mm 39.5 mm 11.5 mm .013 Kg
3381 06 00 6 mm 36.5 mm 11 mm 39.5 mm 11.5 mm .007 Kg
3381 08 00 8 mm 46 mm 13 mm 44.5 mm 14.5 mm .033 Kg

Start pressure test point on the system

Additional Product Data:

Series:
  • 3381 Series
Shape:

Straight

Ends Configuration:
  • 6mm Push-to-Connect
  • 6mm Push-to-Connect
  • Some Ends Match

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
