3329 00 04 by Parker | Legris Modular Plug-In Connectors | M65x1.5 Screw Cap | 12 Outlets | 3.46" Length | Straight | Polymer

3329 00 04 by Parker | Legris Modular Plug-In Connectors | M65x1.5 Screw Cap | 12 Outlets | 3.46" Length | Straight | Polymer

Sale price$47.88

by Parker Hannifin
LF 3000 ® Push-In Fittings / Modular Plug-In Connectors:3329 Multi-Connector Screw Cap
Buy More, Save More!
Quantity Price Each
10–39 $45.01
40–79 $40.70
80+ $35.91
Discounts applied in cart/checkout.

Product Data:

Brand:
  • LF 3000®
Series:
  • 3329 Series
Shape:

Straight
Technical Characteristics:
  • Compatible Fluids: Compressed air
  • Working Pressure: Vacuum to 10 bar
  • Working Temperature: -20°C to +80°C
Advantages:
  • 3 types of solutions: in-line, panel-mounted or DIN rail connector
  • Minimized connection space
  • Prevents incorrect assembly
  • Customized multi-connectors upon request
Regulations:
  • ISO 14743
  • PED
  • RoHS
  • REACH
Component Materials:
  • Panel-mounted: Zinc-Plated Steel, Technical Polymer
  • In-Line: Aluminum, Technical Polymer
  • DIN Rail: Technical Polymer
Part Number C Number of Outlets G G1 L Kg
3329 00 02 M40x1.5 4-7 35 mm 50 mm 55 mm .062 Kg
3329 00 03 M58x1.5 12 34 mm 70 mm 70 mm .139 Kg
3329 00 04 M65x1.5 12 2.01" - 3.46" .122 Kg
‘
