3130 56 10 by Parker | Legris | 1/4" Tamper Proof Safety Clip | White | Polymer

3130 56 10 by Parker | Legris | 1/4" Tamper Proof Safety Clip | White | Polymer

Sale price$0.55

by Parker Hannifin
LF 6100® Push-In Fittings:3130 Tamper-Proof Safety Clip
Buy More, Save More!
Quantity Price Each
20–39 $0.52
40–79 $0.47
80+ $0.41
Discounts applied in cart/checkout.

Product Data:

Series:
  • 3130 Series
Shape:

No Orientation

Material(s):
  • Polymer
Technical Characteristics:
  • Compatible Ranges: LF3000®, LIQUIfit®
  • Working Temperature: -30°C to +95°C
  • Component Materials: Tamper-proof safety clip, release button cover, clip: technical polymer
Advantages:
  • Safety: Protection of operators and equipment
  • Prevents accidental disconnection
  • Identification: 6 color coding for fluid circuit identification
  • Easy disconnection with dismounting tool
Part Number ØD H K Kg
3130 06 10 6 mm 7.8 mm 3.1 mm .001 Kg
3130 10 10 10 mm 10.8 mm 4.2 mm .002 Kg
3130 56 10 1/4" 8 mm 3 mm .001 Kg
3130 12 10 12 mm 12.5 mm 5.1 mm .003 Kg

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
