3130 56 01 by Parker | Legris | 1/4" Tamper Proof Safety Clip | Black | Polymer | Pack of 100

3130 56 01 by Parker | Legris | 1/4" Tamper Proof Safety Clip | Black | Polymer | Pack of 100

Sale price$59.88

Package Quantity: 100 Units

Buy more, save moreDiscounts applied in cart/checkout.
Technical Characteristics:
  • Compatible Ranges: LF3000®, LIQUIfit®
  • Working Temperature: -30°C to +95°C
  • Component Materials: Tamper-proof safety clip, release button cover, clip: technical polymer
Advantages:
  • Safety: Protection of operators and equipment
  • Prevents accidental disconnection
  • Identification: 6 color coding for fluid circuit identification
  • Easy disconnection with dismounting tool
Part Number ØD H K Kg
3130 06 01 6 mm 7.8 mm 3.1 mm .001 Kg
3130 08 01 8 mm 9.5 mm 4.3 mm .001 Kg
3130 56 01 1/4" 8 mm 3 mm .001 Kg
3130 12 01 12 mm 12.5 mm 5.1 mm .003 Kg

Additional Product Data:

Series:
  • 3130 Series
Shape:

No Orientation

Material(s):
  • Polymer

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
